Hongfa HFD2/024-S-L2-D PCB relay 24 V DC 3 A 2 change-overs 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 2.34
10
7% = € 0.17
€ 2.17
25
10% = € 0.24
€ 2.10
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 2.34 / piece)
€
Technical specifications
- Type
HFD2/024-S-L2-D
- Coil nominal voltage
24 V DC
- Min. pick-up voltage
19.2 V DC
- Max. pick-up voltage
55.4 V DC
- Control mode
bi-stable, 2 coil
- Resistance (coil)
3840 Ω
- Contact type
2 change-overs
- Contact material
Ag-AuAg8
- Switching voltage (max.)
220 V DC
250 V AC
- Switching current (max.)
3 A
- Max. switching capacity
90 W
125 VA
- Connection
Solder pins
- Min. temperature
-40 °C
- Max. temperature
+85 °C
- Length
20.2 mm
- Width
10.2 mm
- Height
10.6 mm
- Dim
(L x W x H) 20.2 x 10.2 x 10.6 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
- Product type
PCB relay
