i-PRO Panasonic WJ-PR201E

i-PRO WJ-PR201E - Coax LAN converter receiver unit with 1 channel (PoE/PoE+ | Transmission distance: 300m (PoE+) / 500m (PoE) / 2km (normal connection) - in silver

1-channel receiver side unit for easy switchover from analogue technology to an IP-system
The coaxial LAN converter can be used for distances up to 300 m for PoE+ connections, 500 m for PoE connections and 2.0 km for non-PoE+ connections. (When used with the RG-6/U coaxial cable, the loop resistance without additional parts is less than 4 O/100 m.)Fast transfer


The coaxial LAN converter achieves a transfer speed of at least 35 Mbps via TCP and at least 45 Mbps for UDP connections.
(When used with RG-6/U coaxial cable and for distances less than 2.0 km [PR201], 500 m [PR204]<><>

Connections can be made by connecting the coaxial cable to the coaxial LAN converters.



1-channel receiver unit

Use over long distances

Power over Ethernet plus (PoE+) enabled

The coaxial LAN converter is compatible with PoE+ (IEEE802.3at) and PoE+ cameras can be connected and used.

Power supply with AC adapter (included): INPUT 100 - 240 V 50/60 Hz , OUTPUT : DC 57 V / 1.14 A | PoE: DC 48V / approx. 265 mA

Power consumption with AC adapter: DC 57 V / 700 mA / approx. 40 W | PoE: DC 48 V / 265 mA / approx. 12.95 W.

Dimensions (WxDxH) 105 x 44 x 98mm

Weight approx. 250g
