i-tec USB4® / Thunderbolt™ 4 docking station TB4DUALDPDOCKPDPRO
EAN:
Part number:
Item no:
Datasheet (PDF)
i-tec TB4DUALDPDOCKPDPRO USB4® / Thunderbolt™ 4 docking station
Highlights & Details
- Connection A (or inputs): Thunderbolt 4
- Connecton B (or outputs): USB
- No. of supported monitors:
- Maximum resolution:
- Key features:
Technical specifications
- Transmission technology: Cable-bound
- Host Interface: Thunderbolt 4
- Number of USB 2.0 connections 1
- USB 3.2 Gen 1 (3.1 Gen 1) Number of ports Type A: 2
- USB 3.2 Gen 1 (3.1 Gen 1) Number of C-type connectors: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Number of ports Type A: 2
- USB 3.2 Gen 2 (3.1 Gen 2) Number of C-type connectors: 1
- USB Power delivery: Yes
- USB power supply up to 92 W
- Number of DisplayPort connections: 2
- Number of Thunderbolt 4 ports 2
- Combined headphone/microphone connection: Yes
- 3.5 mm headphone jack
- Ethernet/LAN: Yes
- Number of Ethernet LAN connections (RJ-45): 1
- Ethernet LAN data transfer rates of 10,100,1000,2500 Mbit/s.
- Integrated card reader: Yes
- Compatible memory cards: MicroSD (TransFlash), SD
- Data transfer rate 40 Gbps
- Resolution (maximum, digital) 7680 x 4320 pixels
- Number of display supported: 2
- Maximum frame rate 60 Hz
- Output voltage 28 V
- Output current: 5 A
- Thunderbolt 4 cable length 1 m
- Supports Windows operating systems: Yes
- Supports Mac operating systems: Yes
- Supported Linux operating systems: Yes
- Height (front): 28.6 cm
- Supplied cable: Thunderbolt, USB type-C
- AC mains adapter: Yes
- Quick start overview: Yes
- Product type
USB4® / Thunderbolt™ 4 docking station
- Type A
Thunderbolt 4
- Type B
USB
- Suitable for
Notebook
Tablet
iPad
MacBook
- Cable length
0 cm
- Factory colour
Black
- Width
197 mm
- Height
30 mm
- Depth
79 mm
- Weight
1.057 kg
- Dim
(W x H x D) 197 x 30 x 79 mm
- Frame rate
60 Hz
- Design height
30 mm
- No. of 10 Gb LAN ports
1 x
- No. of DisplayPort
2 x
- No. of Thunderbolt IFs
2 x
- No. of USB ports
1 x
- No. of USB A 2.0 ports
1 x
- No. of USB type A 3.1 / 3.2 1st Gen
2 x
- No of. USB type A 3.1 /3.2 2nd gen
2 x
- No. of USB 3.0 ports
1 x
- Supported memory cards
microSD
SD
- Transfer rate
40 GBit/s
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3221964 i-tec USB4® / Thunderbolt™ 4 docking station TB4DUALDPDOCKPDPRO
User & Safety Instructions
User & Safety Instructions 3221964 i-tec USB4® / Thunderbolt™ 4 docking station TB4DUALDPDOCKPDPRO
Description
Extraordinary performance, ultra-fast data transfer and support for a resolution of up to 8K. One of the most powerful docking stations on the market!
Crystal-clear picture quality, super-fast Internet and the possibility of transferring data with a speed of up to 4 GB per second, thanks to the integrated Thunderbolt" 4-output port. Of course, you can also connect your headphones or audio devices and charge your notebook (92 W) – all via a single cable.
Thanks to the integrated DP 1.4 protocol, you can connect this docking station to a monitor with a resolution of up to 8K (7680 x 4320) with a refresh rate of 30 Hz, WAS corresponds to the resolution of four monitors each with 4K resolution. This makes it the ideal solution for graphic designers, analysts, developers, film editors or high-definition video enthusiasts and enthusiasts.
The dock is now not only compatible with Thunderbolt" 4 ports, but also with USB-C*, WAS makes it a flexible solution for companies and users who operate laptops and tablets with different ports.
* When connected to USB-C, only one monitor (4K/60 Hz) is supported.
This text is machine translated.
Crystal-clear picture quality, super-fast Internet and the possibility of transferring data with a speed of up to 4 GB per second, thanks to the integrated Thunderbolt" 4-output port. Of course, you can also connect your headphones or audio devices and charge your notebook (92 W) – all via a single cable.
Thanks to the integrated DP 1.4 protocol, you can connect this docking station to a monitor with a resolution of up to 8K (7680 x 4320) with a refresh rate of 30 Hz, WAS corresponds to the resolution of four monitors each with 4K resolution. This makes it the ideal solution for graphic designers, analysts, developers, film editors or high-definition video enthusiasts and enthusiasts.
The dock is now not only compatible with Thunderbolt" 4 ports, but also with USB-C*, WAS makes it a flexible solution for companies and users who operate laptops and tablets with different ports.
* When connected to USB-C, only one monitor (4K/60 Hz) is supported.
This text is machine translated.
Features
- Transmission technology: Cable-bound
- Host Interface: Thunderbolt 4
- USB power supply up to 92 W
- Ethernet LAN data transfer rates of 10,100,1000,2500 Mbit/s.
- Product color: Black
- Compatible memory cards: MicroSD (TransFlash)
- SD
- Data transfer rate 40 Gbps
- Output voltage 28 V
- Output current: 5 A
- Thunderbolt 4 cable length 1 m
- Width: 197 mm
- Depth: 79 mm
- Height: 30 mm
