Buy ifm Electronic AC2520 AC2520 GPI module M12 plug No. of digital inputs: 4

Image similar

Product type

GPI module

Interfaces

M12 plug

Type

AC2520

No. of digital inputs

Control LEDs

Yes

Datasheet (PDF)

Unavailable

Sales and shipping:

Highlights & Details

Easy mounting and wiring
Connection of the AS-i flat cable using module subsections
Highly visible, bright LEDs for displaying operation, switching status and errors
High protection class to meet the requirements of harsh industrial ambient
Durable M12 connectors for connecting sensors and actuators

Number of analog inputs: Connection of 2 and 4 wire sensors
Number of inputs and outputs: Number of Pt100 inputs: 4
Number of Pt100 inputs: 4
Display: Switching state: LED, yellow channels AI1...AI4; operation: LED, green voltage AS-i - AS-i; error: LED, red
Ambient temperature-1 [°C]: 0...70
Tightening torque [Nm]: 0.6...0.8
Application: Field mounting
AS-i Addressing: Addressing socket; IR addressing possible
AS-i I/O Configuration [HEX]: 7
AS-i ID code [HEX]: 3.E
As-i Master profile M3; M4
AS-i profile S-7.3.E
Analogue input resolution 16 / 0.1 ° C.
Operating voltage [V]: 26.5... 31.6 DC
Weight [g]: 205,550
Short-circuit resistance of digital inputs: Yes
Storage temperature [°C]: -25...85
Max. Current consumption from AS-i [mA]: 80
Measuring range [°C]: -200...850
Module connection: Flat cable
AS-i interface to FK- parts
MTTF: 140
IP 67 protection
Sensor supply of inputs: AS-i
Plug connection: Pin layout: 0017 - connector: M12; coding: A.
Current carrying capacity total [A]: 0.08
Reverse polarity protection: Yes
