Buy ifm Electronic AC5223 AC5223 GPI module Ribbon cable No. of digital inputs: 2

Image similar

Product type

GPI module

Interfaces

Ribbon cable

Type

AC5223

No. of digital inputs

Control LEDs

Yes

Datasheet (PDF)

Unavailable

Sales and shipping:

Highlights & Details

Easy installation and wiring without any tools thanks to quick mounting technology
Three freely selectable alignments of the flat cable
Highly visible, bright LEDs for displaying operation, switching status and errors
High protection class to meet the requirements of harsh industrial ambient
Durable M12 connectors for connecting sensors and actuators

Analog input current [mA]: 4...20
Number of analog inputs: 2; (connection of 2-, 3- and 4-wire sensors)
Number of inputs and outputs: Number of analog inputs: 2
Display: Analog signal: LED, yellow channels AI1...AI2; operation: LED, green AS-i; error: LED, red
Ambient temperature-1 [°C]: -25...70
Application: Field mounting
AS-i Addressing: Addressing socket
AS-i I/O Configuration [HEX]: 7
AS-i ID code [HEX]: 3.D
As-i Master profile M3; M4
AS-i profile S-7.3.D
AS-i version 2.11; 3.0
12-bit analogue resolution
Operating voltage [V]: 26.5... 31.6 DC
Extended addressing mode: No.
Accuracy: 0.5; (% of the end-of-range value; tolerance under the influence < of electromagnetic interference: ± 1% of the end-of-range value)
Weight [g]: 158,850
Ready-to-assemble connection / terminals: Quick-assembly technology for AS-i flat cable: ; Orientation possible in three directions
Short-circuit resistance of analogue inputs: Yes
Storage temperature [°C]: -25...70
Max. Height above NN [m]: 2000
Max. Voltage drop via load at rated voltage [V]: 10
Max. Current consumption from AS-i [mA]: 250
Max. Permissible relative humidity [%]: 90; (non-condensing)
Module connection: Flat cable
MTTF: 174
IP 67 protection
Sensor supply of inputs: AS-i
Plug connection: Pin layout: 0017 - connector: M12; coding: A.
Reverse polarity protection: Yes
