Buy ifm Electronic AL1010 AL1010 Sensor & actuator box (active) Multi splitter 1 pc(s) Piece

A black electronic module with multiple round connectors for industrial applications against a black background.

Image similar

Packaging type

Piece

Product type

Sensor & actuator box (active)

No. of signal spaces

No. of splitters

8-way

Type

AL1010

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad Electronic Terms & Conditions

Report legal concerns

Highlights & Details

Ifm AL1010 IO-Link Master Powerline

Reliable transmission of machine data, process parameters and diagnostic data to the controller
With integrated fieldbus interface
Large operating temperature range and high protection class
Robust housing for use in rough industrial environment
For connecting up to eight IO-Link devices

Technical specifications

Output power supply: 24 V DC
Number of digital outputs: 8; (IO-Link Port Class A: 4 x 1; IO-Link Port Class B: 4 x 1)
Number of digital inputs: 12; (IO-Link Port Class A: 4 x 2; IO-Link Port Class B: 4 x 1)
Number of inputs and outputs: Number of digital inputs: 12; number of digital outputs: 8
Number of ports Class A - IO-Link Master: 4
Number of ports Class B - IO-Link Master: 4
Ambient temperature-1 [°C]: -25...60
Application: I/O modules for field use
OPERATING VOLTAGE [V]: 19...31.2 DC; (US)
Loop-through function: Power supply; field bus interface
Total number of inputs and outputs: 12; (configurable)
Weight [g]: 577,000
IO-Link revision - IO-Link Master: 1.1
Communication interface: IO-Link; PROFIBUS
Short-circuit-proof: Yes
Short-circuit resistance of digital inputs: Yes
Storage temperature [°C]: -25...85
Max. Permissible relative humidity [%]: 95
Switching level HIGH [V]: 15...30
Switching level Low [V]: -3...5
Protection class IP 65; IP 67
Protection class III
Plug connection: Process connection - Pin layout: 0017 - Plug connection: M12; Coding: A; Seal: FKM / PROFIBUS IN - Pin layout: 0163 - Connector: M12; Coding: B / PROFIBUS OUT - Pin layout: 0162 - Connector: M12; Coding: B; Seal: FKM / voltage supply IN - Pin layout: 0183 - Connector: M12; Coding: T / Power supply OUT - Pin layout: 0182 - Connector: M12; Coding: T; Seal: FKM
Power rating per output [mA]: 200
Current rating per port - actuator supply_UA [A]: 1.6
Current rating per port - Sensor supply_US [A]: 0.2
Transmission type - IO-Link Master: COM1 (4.8 kBaud); COM2 (38.4 kBaud); COM3 (230.4 kBaud)
Material seal: FKM
Additional power supply [V]: 19...31.2 DC; (UA)
