Name: ifm Electronic DV1001 LED strip DV1001 1 pc(s)
Brand: ifm Electronic
SKU: 3320466

Image similar

Product type

LED strip

Type

DV1001

Min. operating voltage

21.6 V DC

Max. operating voltage

26.4 V DC

Operating voltage

21.6 - 26.4 V DC

Datasheet (PDF)

Unavailable

Sales and shipping:

Highlights & Details

Ifm DV1001 LED strip RGBW

LEDs in the colors red, green, blue and white can be activated via individual connections
Extremely robust, fully cast design with protection class IP 68
Curved or straight mounting
High light yield through powerful LEDs

Dimensions [mm] 265 x 14.2 x 4.5
Display: Indication of machine conditions: LED, multi-colored RGB; mounting light: LED, white
Ambient temperature-1 [°C]: -20...45
Application: Signaling of machine states
Operating voltage [V]: 21.6... 26.4 DC
Input connection digital inputs 24 V PNP
Colour temperature [K]: 4000
Weight [g]: 47,800
Cable 0.3 m
Luminous flux [lm]: Red: 101.2; green: 188.8; blue: 37; white: 285.2
Max. Height above NN [m]: 4000
Max. Permissible relative humidity [%]: 90
Rated voltage DC [V]: 24; (according to SEL/PEL)
Protection class:IP 68
Plug connection: Pin layout: 0063 - connector: M12; coding: A.
Current consumption: 400
Type. Life span [h]: 30000
Pollution level: 2
IEC 62471; IEC 62031
