Buy ifm Electronic E84016 PSU E84016 1 pc(s)

An orange power supply unit from ifm with model number E84016, input range AC 100-240V and output DC 24V/4A.

Image similar

Product type

PSU

Type

E84016

Max. operating voltage

230 V AC

Operating voltage

230 V AC (max)

Content

1 pc(s)

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad Electronic Terms & Conditions

Report legal concerns

Highlights & Details

Ifm E84016 switched mode power supply 24 V DC

For regulated power supply for control systems, sensors, actuators and industrial electronics
Low power loss thanks to Hohem efficiency
High power failure bridging time
Deactivation of the device is possible by means of a signal transmitter
High power reserves

Technical specifications

Dimensions [mm] 124 x 126 x 132.6
Number of output circuits: 1
Display: DC ok 1 x LED; overload 1 x LED
Ambient temperature-1 [°C]: -25...70
Design DC-OK-Signal: Relay output
Output power (permanent) [W]: 960
Output power (short term) [W]: 1440
Output voltage [V]: Adjustable, output voltage according to SEL, PEL
Output voltage DC [V]: 24...28
RATING DC-OK SIGNAL: 60 V DC (0.3 A) / 30 V DC (1 A) / 30 V AC (0.5 A)
Operating voltage tolerance [%]: 15...10
DERATING [W/K]: 24 (60...70 °C)
Input voltage range AC [V]: 100...240
Input current (rated voltage 120 V AC / 60 Hz) [A]: 8.6
Input current (rated voltage 230 V AC / 50 Hz) [A]: 4.5
Peak switch-on current (nominal voltage 120 V AC / 60 Hz) [A]: 17
Peak switch-on current (nominal voltage 230 V AC / 50 Hz) [A]: 11
Switch-on current limitation: Yes
External input protection ≥ B-16 A / ≥ C-16 A
Frequency AC [Hz]: 47...64
Weight [g]: 2044,500
Field ready for connection / terminals: Screw terminals:
Short-circuit-proof: Yes
Storage temperature [°C]: -40...85
Power factor (nominal voltage 120 V AC / 60 Hz): 0.99
Power factor (nominal voltage 230 V AC / 50 Hz): 0.99
PFC power factor correction: Satisfied
Power reserve [%]: 50
Max. Output current at max. Output voltage [A]: 34.3
Max. Output current at min. Output voltage [A]: 40
Max. Output current, short-term at max. Output voltage [A]: 51.5
Max. Output current briefly at min. Output voltage [A]: 60
Max. Remaining ripple [mV]: 100
Max. Permissible relative humidity [%]: 95; (IEC 60068-2-30)
Mounting type: Support rail; (TH35 (EN 60715))
Nominal voltage AC [V]: < 230
Power outage bridging time (nominal voltage 120 V AC / 60 Hz) [ms]: 27
Power outage bridging time (nominal voltage 230 V AC / 50 Hz) [ms]: 27
Regenerative resistance [V]: 35
IP 20; (EN 60529)
Protection class I; (IEC 61140)
Overload-proof: Yes
Overload behavior: Hiccup mode; with overload or short-circuit, the output provides alternating current for 2 s and then switches off for 17 s.
Voltage surge protection: Yes; (< 32 DC)
Power loss (nominal voltage 120 V AC / 60 Hz) [W]: 65.6
Power loss (nominal voltage 230 V AC / 50 Hz) [W]: 54.8
Pollution level 2; (IEC 62103: Conductive contamination not permitted)
Efficiency (nominal voltage 120 V AC / 60 Hz) [%]: 93.6
Efficiency (nominal voltage 230 V AC / 50 Hz) [%]: 94.6
