Two orange, L-shaped cable plugs with metallic threads are positioned side by side against a black background.

Image similar

Product type

Cable connection

Connector type

Plug, right angle

Socket, right angle

Connection side A

M12

Connection side B

M12

No. of pins

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad Electronic Terms & Conditions

Report legal concerns

Highlights & Details

Ifm EVT079 Connecting cable

For use in hygiene and wet areas in the food industry
Durable, reliable sealing even with tool-free mounting
Large operating temperature range and high protection class
Vibration and shock proof thanks to the swivel nut and vibration proof
Reliable protection of the O-ring against destruction by mechanical fixed stop

Technical specifications

Dimensions [mm] 30.5 x 15.5 x 36.5
Drag-chain compatibility: Bending radius when used flexibly: Min. 10 x cable diameter; traverse speed: Max. 3.3 m/s at 5 m horizontal traverse length and max. Acceleration of 5 m/s²; bending cycles: > 1 MIO.; torsional load: ± 180 °/m.
Drag chain capability available: Yes
Ambient temperature-1 [°C]: -25...100
Application: Hygiene and wet areas in the food industry
Special feature: Silicone-free; gold-plated contacts; suitable for drag chains
OPERATING VOLTAGE [V]: < 250 AC / < 300 DC
Weight [g]: 42,700
Cable 2 - Cable: 0.3 m, PVC, orange, Ø 4.9 mm, 3 x 0.34 mm² (42 x Ø 0.1 mm)
Storage humidity [%]: 10...100
Storage temperature [°C]: -25...55
PROTECTION CLASS IP 65; IP 67; IP 68; IP 69K
Protection class: II
Silicone-free: Yes
Plug connection: 1.Plug - Pin layout: 0061 - Plug connection: 1 x M12, angled; Coding: A; Lock: 1.4404 (Stainless steel / 316L); Contacts: Gold-plated; Tightening torque: 0017...1.5 Nm / 3.Socket - Pin layout: 0.6 - Connector: 1 x M12, angled; Coding: A; Lock: 1.4404 (Stainless steel / 316L); Contacts: Gold-plated; Tightening torque: 0.6...1.5 Nm
Current carrying capacity total [A]: 4
Ambient temperature, moving [°C]: 5...100
Cap nut material: 1.4404 (stainless steel / 316L)

Packaging type: Piece

Type: EVT079

Product type: Cable connection

Connector type: Plug, right angle
Socket, right angle

Connection side A: M12

Connection side B: M12

No. of pins: 3
5

Cable length: 0.3 m

Jacket material: PVC

Nominal voltage: 250 V AC
300 V DC

Connector cross-section (max.): 0.34 mm²

Cross-section (sensor/actuator wiring): 0.34 mm²

Connection: M12 plug
M12 socket

Thread type connection side: M12

Thread type (wiring and installation): M12

Coding: A
A

Contact material: Gold plated contacts

Contact surface: Gold plated

max. cross section: 0.34 mm²

Features: Twistable
Silicone-free
PVC
Suitable for drag chains
Shake-proof

Min. temperature: -25 °C

Max. temperature: 100 °C

Manufacturer part #: EVT079

Content: 1 pc(s)

Cable Ø: 4.9 mm

Cable Ø (max.): 4.9 mm

Cable Ø range: 4.9 mm (max)

UKCA: yes
