ifm Electronic Fibre optics E20757 E20757 1 pc(s)
EAN:
Part number:
Item no:
Packaging type
Single
Product type
Fibre optics
Type
E20757
Cable length
2000 mm
Enclosure material
Aluminium
Datasheet (PDF)
Highlights & Details
Ifm E20757 one-way light barrier
- For installation in awkward spaces
- Operating as one way light barrier
- With cross-section converter for reliable recording of objects with adjustable position
- Length self assembled
- Small bending radius
Technical specifications
- Dimensions Probe [mm] 5 x 20 x 20
- Functional principle opto: One-way light barrier
- Ambient temperature-1 [°C]: -40...70
- Application: Small bending radius
- Design: Cross-section converter
- FOA-E01 fiber arrangement
- Total length [mm]: 2000
- Weight [g]: 61,000
- Core diameter [mm]: 16 x 0.25
- Light guide material: Aluminium
- Fibre optic cable jacket material PE
- Optical fiber material PMMA
- Minimum bend radius [mm]: 9
- Fibre optic range - OB50 [mm]: 150
- Fibre optic range - OBF [mm]: 300
- Fibre optic range - OCF [mm]: 2040
- Fibre optic range - OO50 [mm]: 700
- Range with fiber optic amplifier type: OB50; OBF; OCF; OO50
- Probe width [mm]: 20
- Probe height [mm]: 5
- Probe length [mm]: 20
- Packaging type
Single
- Product type
Fibre optics
- Type
E20757
- Cable length
2000 mm
- Enclosure material
Aluminium
2040 mm
- Features
Bend-proof cable
- Min. temperature
-40 °C
- Max. temperature
70 °C
- Length
20 mm
- Width
20 mm
- Height
5 mm
- Dim
(L x W x H) 20 x 20 x 5 mm
- Content
1 pc(s)
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3319031 ifm Electronic Fibre optics E20757 E20757 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3319031 ifm Electronic Fibre optics E20757 E20757 1 pc(s)
Description
Ifm E20757 one-way light barrier
This text is machine translated.
This text is machine translated.
Hints
For more information on this E20757, please refer to its datasheet under 'downloadable documents'
