ifm Electronic Fibre optics E21105 E21105 Retroreflective 1 pc(s)
EAN:
Part number:
Item no:
Product type
Fibre optics
Functions
Retroreflective
Type
E21105
Cable length
2000 mm
Enclosure material
PE
Datasheet (PDF)
Highlights & Details
Ifm E2105 reflective light sensor
- For installation in awkward spaces
- Operates as light sensor
- High sensor width
- Length self assembled
- Highly flexible design for extremely small bending radii
Our service for you
Technical specifications
- Functional principle opto: Reflection light sensor
- Ambient temperature-1 [°C]: -40...60
- Application: Small bending radius
- Probe head type: Straight
- Outer diameter [mm]: 2.2
- FOA-R03 fiber arrangement
- Fibre diameter [mm]: 2x 613 x 0.06
- Total length [mm]: 2000
- Weight [g]: 49,500
- Core diameter [mm]: 1.2
- Light guide material: Aluminium
- Fibre optic cable jacket material PE
- Optical fiber material PMMA
- Minimum bend radius [mm]: 3
- Probe thread M6
- Probe length [mm]: 35
- Feeler gauge for fiber optics – OB50 [mm]: 70
- Feeler gauges, fiber optics – OBF [mm]: 104
- Feeler gauge for fiber optics – OCF [mm]: 620
- Feeler gauge for fiber optics – OO50 [mm]: 180
- Scan width with fiber optic amplifier type: OB50; OBF; OCF; OO50
- Product type
Fibre optics
- Type
E21105
- Functions
Retroreflective
- Cable length
2000 mm
- Enclosure material
PE
620 mm
- Features
Bend-proof cable
- Min. temperature
-40 °C
- Max. temperature
60 °C
- Length
35 mm
- (Ø)
2.2 mm
- Dim
(Ø x L) 2.2 mm x 35 mm
- RoHS-compliant
Yes
- Content
1 pc(s)
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3319666 ifm Electronic Fibre optics E21105 E21105 Retroreflective 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3319666 ifm Electronic Fibre optics E21105 E21105 Retroreflective 1 pc(s)
Description
Ifm E2105 reflective light sensor
This text is machine translated.
This text is machine translated.
Hints
For more information on this E21105, please refer to its datasheet under 'downloadable documents'
