Name: ifm Electronic Magnetic sensor Magnetic MGT201 MGT201 M18 x 1 PNP (Ø x L) 18 mm x 60 mm
Brand: ifm Electronic
SKU: 3318943

Highlights & Details

Ifm MGT201 Magnetic sensor

High switching distance even through non-magnetizing metals: For the detection of moles
Temperature stable and reproducible switching point
High protection class for the requirements of the food and drink industry
High operating temperature range
Food grade full metal housing

Dimensions [mm]: M18 x 1 / L = 60
Reaction sensitivity [MT]: 0.3
Display: Switch status 1 x LED, yellow
Ambient temperature-1 [°C]: 0...104
Application: Dairy holder
Output function: Closer
Special feature: Gold-plated contacts
Operating voltage [V]: 10... 30 DC
Continuous current carrying capacity of the switching output DC [mA]: 200
Electrical version: PNP
Housing: Threaded design
Weight [g]: 47,300
Thread name M18 x 1
Hysteresis: 1...10
Pulse extension [ms]: 1000
Short-circuit protection: Yes
max. Voltage drop switch output DC [V]: 2.5
MTTF: 769
Test mark (special cases): CCC
Switching distance [mm]: 100; (relative to magnet M 4.0)
PROTECTION CLASS IP 68; IP 69K
Protection class III
Plug connection: Plug - pin layout: 0001 - plug connection: 1 x M12; coding: A; contacts: Gold-plated
Current consumption: < 10
Overload-proof: Yes
Reverse polarity protection: Yes
