Name: ifm Electronic OMH550 Optical proximity sensor 1 pc(s) Max. range (open field): 0.08 m (L x W x H) 51 x 51 x 17 mm
Brand: ifm Electronic
SKU: 3321606

Image similar

Packaging type

Piece

Product type

Optical proximity sensor

Min. operating voltage

10 V DC

Max. operating voltage

30 V DC

Max. range

0.08 m

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

Ifm OMH550 Optical distance sensor

Optical distance measurement in the micrometer range
Two switch outputs
Suitable for high-frequency applications
Three operating modes and robust, compact design make a broad range of applications possible
Visualization of the distance value via IO-Link
Convenient operation via keys or parameterization via IO-Link

Technical specifications

Dimensions [mm] 51 x 51 x 17
Number of digital outputs: 2
Number of digital inputs: 1
Number of inputs and outputs: Number of digital inputs: 1; number of digital outputs: 2
Display: Switching state: 2 LED, yellow; supply voltage: 1 LED, green; operating mode: 5 LED, white
IO-Link Revision: 1.1
SDCI standard IEC 61131-9
Transmission type IO-Link: COM2 (38.4 kBaud)
Ambient temperature-1 [°C]: 0...60
Tightening torque [Nm]: 5
Resolution [mm]: 0.01
Output function: NO/NC contact; (can be parameterized)
Required master port class: A
Standby delay time [s]: < 0.3
Operating voltage [V]: 10...30 DC; ("supply class 2" according to cULus)
Continuous current carrying capacity of the switching output DC [mA]: 100
Inputs: Laser on / off
Electrical design: PNP/NPN; (parameterizable)
Housing: Square
Total number of outputs: 2
Weight [g]: 129,000
Accuracy/Variance Notes: The specified values are reached after a 20 minute warm-up time.
IO-Link functions (acyclic): Application-specific marking; operating hours counter
Communication interface: IO-Link
Short-circuit protection: Yes
Storage temperature [°C]: -10...65
Laser protection class 1
Type of light: Red light
Light spot dimensions apply to: At maximum range
Max. Light spot diameter [mm]: 0.5
max. Voltage drop switch output DC [V]: 2.2
Measuring range [m]: 0.03...0.08; (6...90% friction)
Min Process cycle time [ms]: 3.2
MTTF: 572
Parameterisation options: Hysteresis/window/2-point; switch-on and switch-off delay; switch-on processes; teach-function; filter; Light / dark switching; laser switch-off; operating mode
Profiles: Measuring and switching sensor, 1 channel, identification and diagnosis, sensor control, teach two value, Locator, ProductURI
Test mark (special cases): CCC
Range/width adjustable: Yes
Reproducibility [mm]: 0.03
Switching frequency DC [Hz]: 200
Protection class IP 65; IP 67
Protection class III
SIO mode: Yes
Plug connection: Pin layout: 0063 - plug connection: 1 x M12; coding: A.
Current consumption: < 60
Teach function: Yes
Temperature compensation: Yes
Type. Life span [h]: 50000
Overload-proof: Yes
Reverse polarity protection: Yes
Wavelength [nm]: 630
