Buy ifm Electronic PP2001 Programmer PP2001 1 pc(s)

Image similar

Product type

Programmer

Type

PP2001

Content

1 pc(s)

RoHS-compliant

Yes

UKCA

yes

Datasheet (PDF)

Unavailable

Sales and shipping:

Highlights & Details

For diagnostics and parameterization of pressure sensors
Automatic detection of the type, measuring range and current parameter set of the sensor
The display of the current measured value of the sensor
Easy transfer of the parameter set of a sensor to other sensors of the same type

Dimensions [mm] 100 x 34 x 48
Display: Display unit: 6 x LED, green; switching state: 2 x LED, yellow; function display: Alphanumeric display, 4-digit; values: Alphanumeric display, 4 digit
Ambient temperature-1 [°C]: -25...80
Application: For industrial use
Short-circuit protection version: Synchronised
Standby delay time [s]: 1.5...10; (depending on connected sensor)
Special feature: Gold-plated contacts
Operating voltage [V]: 18... 32 DC
Continuous current carrying capacity of the switching output DC [mA]: 250
Weight [g]: 333,500
Short-circuit protection: Yes
Storage temperature [°C]: -40...100
Max. Measurement/display cycle time [ms]: 200
max. Voltage drop switch output DC [V]: 2
Min INSULATION RESISTANCE [MΩ]: 100; (500 V DC)
MTTF: 229
Parameterization options: Depending on the connected sensor
Protection class IP 67; (for device with screwed on connectors)
Protection class III
Plug connection: Pin layout: Zero - connector: 1 x M12; contacts: Gold-plated
Current consumption: < 40
Overload-proof: Yes
Reverse polarity protection: Yes
