Name: ifm Electronic Tachometer MX5000 7 - 30 V DC (Ø x L) 15 mm x 70 mm 1 pc(s)
Brand: ifm Electronic
SKU: 3318367

Image similar

Product type

Tachometer

Max. operating voltage

30 V DC

Content

1 pc(s)

Type

MX5000

Connection

AMP Junior timer

Datasheet (PDF)

Unavailable

Sales and shipping:

Highlights & Details

Ifm MX5000 speed sensor

Dimensions [mm]: Ø 15 / L = 70
Working distance [mm]: 1
Ambient temperature-1 [°C]: -32...140
Ambient temperature-2 [°C]: 125
Tightening torque [Nm]: 7
Operating voltage [V]: 7... 30 DC
Continuous current carrying capacity of the switching output DC [mA]: 50
Electrical version: NPN
Weight [g]: 23,500
Short-circuit protection: No.
MTTF: 2247
Shaft length [mm]: 45
Switching distance [mm]: 1.7; (The use of gears with other module influences shifting distance and phase position.)
Switching frequency DC [Hz]: 2...15000
Protection class IP 67; IP 69K; (Plug: IP 54)
Protection class III
Plug connection: Pin layout: Zero plug connector 1 x AMP Junior Timer (282 192-1)
Current consumption: < 30
Reverse polarity protection: No.
Gear module [mm]: 1.25
