Buy ifm Electronic TK6110 TK6110 PT1000 Temperature switch -20 up to 140 °C 0.1 K Antivalent

Industrial pressure sensor in close-up, showing thread and indicator ring for precise pressure measurement in machinery.

Image similar

Product type

Temperature switch

Model

PT1000

Temperature reading range (min.)

-20 °C

Temperature reading range (max.)

140 °C

Connector

M12

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad Electronic Terms & Conditions

Report legal concerns

Highlights & Details

Ifm TK6110 electronic temperature switch

Simple switching point setting with two optimally readable adjusting rings
Setting the switching points without the system temperature being applied
Two analog switching outputs with adjustable hysteresis
Especially good response dynamics and very short delay time
Mechanical locking prevents accidental adjustment

Technical specifications

Response dynamics T05/T09 [s]: 1 / 3; (according to DIN EN 60751)
Number of digital outputs: 2
Number of inputs and outputs: Number of digital outputs: 2
Display: Operation: LED, green; switching status: LED, yellow
1 x Pt 1000; (to DIN EN 60751, Class A)
Switching point adjustment: Adjustment rings
Ambient temperature-1 [°C]: -40...80
Tightening torque [Nm]: 35
Short-circuit protection version: Synchronised
Output function: Earlier
Output signal: Switching signal
Standby delay time [s]: 0.5
Special feature: Gold-plated contacts
Operating voltage [V]: 9.6...32 DC; ("supply class 2" according to cULus)
Continuous current carrying capacity of the switching output DC [mA]: 500
Compressive strength [bar]: 400
Mounting length EL [mm]: 50
Setting accuracy [K]: ± 3
Electrical version: PNP
Total number of outputs: 2
Weight [g]: 104,500
Short-circuit protection: Yes
Storage temperature [°C]: -40...100
max. Voltage drop switch output DC [V]: 2
Media: Liquid and gaseous media
Medium temperature [°C]: -40...145
Measuring range [°C]: -20...140
Measuring range [°F]: -4...284
MTTF: 643.1
Process connection: Thread connection G 1/4
Return point RP [°C]: -20...136
Return point RP [°F]: -4...277
Switching point SP [°C]: -16...140
Switching point SP [°F]: 3...284
IP 67 protection
Protection class III
Rod diameter [mm]: 6
Plug connection: Pin layout: 0001 - plug connection: 1 x M12; code: A; contacts: Gold-plated
Current consumption: < 30
Temperature effect per 10 K [K]: 0.1 **)
Overload-proof: Yes
Reverse polarity protection: Yes
Materials in contact with the Medium: 1.4404 (stainless steel / 316L); FKM
Repeatability [K]: ± 0.1
