Buy ifm Electronic Vibration sensor VVB020 18 - 30 V DC 1 pc(s)

A silver, cylindrical sensor housing with labelling and threaded connection on a black background.

Image similar

Product type

Vibration sensor

Min. operating voltage

18 V DC

Max. operating voltage

30 V DC

Content

1 pc(s)

Type

VVB020

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad Electronic Terms & Conditions

Report legal concerns

Highlights & Details

Ifm VVB020 vibration sensor

Condition-oriented maintenance thanks to monitoring of unbalance, roller bearing or gear condition
Large operating temperature range and high protection class for the requirements of harsh industrial ambient
Reliable and permanent monitoring of parameters including raw data acquisition
Integration in Industrial Ethernet systems without switching cabinets and complex cabling
Asynchronous transfer of raw data (BLOB) and integrated operating hours counter

Technical specifications

Number of digital outputs: 2
Number of inputs and outputs: Number of digital outputs: 2
Number of measuring axles: 1
IO-Link Revision: 1.1
Linearity deviation: 2 %
Diagnostics measuring principle: Capacitive
SDCI standard IEC 61131-9: 2013-07
Transmission type IO-Link: COM2 (38.4 kBaud); COM3 (230.4 kBaud)
Ambient temperature-1 [°C]: -30...60
Tightening torque [Nm]: 8
Application: Medium-sized machines, power < 300 kW, speed > 600 rpm
Resolution - Temperature measurement [°C]: 0.1
Short-circuit protection version: Synchronised
Output function: Normally open / normally closed contact
Output signal: Switching signal; IO-Link
Required master port class: A
Operating voltage [V]: 18... 30 DC
Diagnostic functions: Self-test
Electrical design: PNP/NPN; (configurable)
Frequency range [Hz]: 2...10000
Accuracy ≤ 4 kHz +/-10 %;≥ 4...10 kHz: < 3 dB
Accuracy [K]: ± 2.5 + (0.2 x (ambient temperature - surface temperature))
Weight [g]: 116,500
In steps of - temperature measurement [°C]: 2
IO-Link functions (acyclic): Filter for v-RMS, a-RMS, a-peak; hysteresis; window; Switching points; switching logic
Communication interface: IO-Link
Short-circuit protection: Yes
Storage temperature [°C]: -30...80
max. Voltage drop switch output DC [V]: 2
Measuring range - Temperature measurement [°C]: -30...80
Measuring range vibration - a_peak_a_RMS [g]: 0...50
Measuring range vibration - a_peak_a_RMS [m/s²]: 0...490.3
Measurement range of vibration - crest: 1...50
Measuring range vibration - v_RMS [mm/s]: 0...45
Min INSULATION RESISTANCE [MΩ]: 100; (500 V DC)
Min Process cycle time [ms]: 3.6
Mounting screw
MTTF: 299
Parameterisation options: Software
Profiles: Blob (0x0030); Measuring sensor (0x800A); Common Profile (0x4000)
Analogue process data: 10
Binary process data: 2
Return point RP - a_peak_a_RMS [g]: 0...49.8
Return point RP - a_peak_a_RMS [m/s²]: 0...488.3
Return point RP - Crest: 1...49
RP return point - temperature measurement [°C]: -30...78
Return point RP - v_RMS [mm/s]: 0...44.8
Switching point SP - a_peak_a_RMS [g]: 0.2...50
Switching point SP - a_peak_a_RMS [m/s²]: 2...490.3
Switching point SP - crest: 2...50
Switching point SP - Temperature measurement [°C]: -28...80
Switching point SP - v_RMS [mm/s]: 0.2...45
Increment - a_peak_a_RMS [g]: 0.2
Increment - a_Peak_a_RMS [m/s²]: 2
Step width - crest: 1
Increment - v_RMS [mm/s]: 0.2
PROTECTION CLASS IP 67; IP 68; IP 69K
Protection class III
Sensor type: Micro-electromechanical system (MEMS)
SIO mode: Yes
Plug connection: Pin layout: 0001 - plug connection: 1 x M12; coding: A; max. Cable length 20 m.
Current consumption: < 50
Power rating per output [mA]: 100
Overload-proof: Yes
Polarity reversal protected: Yes
