Buy ifm Electronic VSE152 Vibration sensor testing circuit VSE152 1 pc(s)

An orange industrial controller with multiple ports and LEDs for status indication. Suitable for sensors and network interfaces.

Image similar

Product type

Vibration sensor testing circuit

Type

VSE152

Max. operating voltage

24 V DC

Operating voltage

24 V DC (max)

Content

1 pc(s)

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad Electronic Terms & Conditions

Report legal concerns

Highlights & Details

Ifm VSE152 diagnostic electronics for vibration sensors

For the reliable vibration monitoring of machines and systems
Condition-oriented maintenance thanks to monitoring of unbalance, roller bearing or gear condition
Dynamic inputs for simultaneous detection of up to four vibration sensors
Two switching outputs for pre-alarm and main alarm
Analog inputs for monitoring other physical measured variables

Technical specifications

Dimensions [mm] 114.2 x 50 x 105.3
Analog output current [mA]: 4...20
Analog input current [mA]: 4...20
Number of analog outputs: 1; (configurable)
Number of analog inputs: 2
Number of digital outputs: 2; (configurable)
Number of dynamic inputs: 4
Number of inputs and outputs: Number of analog inputs: 2; number of dynamic inputs: 4; number of digital outputs: 2; number of analog outputs: 1
Ambient temperature-1 [°C]: 0...60
Application: Continuous vibration monitoring
Analogue input resolution: 12
Design: Parameterisable via PC-software VES004
Short-circuit protection version: Synchronised
Output function: NO/NC contact; (can be parameterized)
Output signal: Switching signal; analogue signal
Operating voltage [V]: 24 DC (when IEPE input is used: 24 + 20%; IEPE = Integrated Electronics Piezo Electric)
Operating voltage tolerance [%]: 20
Continuous current carrying capacity of the switching output DC [mA]: 100
Dynamic Input Resolution [bit]: 16
Dynamic Input - Frequency Range [Hz]: 0.1...12000
Dynamic Input Sampling rate [kSamples]: 100
Dynamic input - signal: 0...10 mA / IEPE / 4...20 mA
Real-time clock: Yes
Electrical version: PNP
Frequency range [Hz]: 0.1...12000
Housing: Plastic housing
Total number of outputs: 2
Total number of inputs and outputs: 8; (configurable)
Total number of inputs: 6
Weight [g]: 413,200
Communication interface: Ethernet
Field attachable connection / terminals: COMBICON:
Short-circuit protection: Yes
Storage temperature [°C]: 0...60
Max. Burden [Ω]: 500
max. Voltage drop switch output DC [V]: 2
Mounting type: Mounting rail; (TH35/EN60715)
MTTF: 91
EtherCAT protocol
Protection class IP 20
Protection class III
Power consumption: 200; (24 V DC)
Overload-proof: Yes
Transfer rate 10 Mbaud; 100 Mbaud
