Iiyama 32" PCAP Anti-Glare, Bezel Free 30-Point Digital signage display EEC: F (A - G) 80 cm 31.5 inch 1920 x 1080 Pixel
EAN:
Part number:
Item no:
Highlights & Details
Iiyama 32" PCAP Anti-Glare, Bezel Free 30-Point Digital signage display
- Screen size diagonal: 80 cm (31.5 inch)
- Display resolution: 1920 x 1080 Pixel
- Energy efficiency rating (calc): F (A - G)
- Anti burn-in function, Fanless design, Kiosk mode, Dust-proof, Safety glass
- Operating time (console): 24/7
Technical specifications
- Protection class IK-7
- Water and dust proof: IP65 (on front)
- Product type
Digital signage display
- Screen size diagonal (inches)
31 inch
- Features
Anti burn-in function
Fanless design
Kiosk mode
Dust-proof
Safety glass
- Display technology
LCD
- Operating time (console)
24/7
- Brightness
500 cd/m²
- Static contrast ratio
3000 : 1
- Viewing angle
178°
- Display resolution
1920 x 1080 Pixel
- Dot pitch (horizontal)
0.364 mm
- Dot pitch (vertical)
0.364 mm
- Image format
16:9
- Frame rate
60 Hz
- Image enhancement
60 Hz
- Controller
Touchscreen
- No. of HDMI connections
1
- No. of USB ports
1 x
- Interfaces
HDMI™
DisplayPort
VGA
- Power supply (details)
100 - 240 V
- Power consumption (standby)
0.5 W
200 x 200 mm
- Factory colour
Black
- Dim
(W x H x D) 746 x 437 x 61 mm
- Width
746 mm
- Height
437 mm
- Depth
61 mm
- Height (without base)
43.7 cm
- Device depth (without stand)
6.1 cm
- Weight
10 kg
- Weight (without base)
10 kg
F (A - G)
- Display
80 cm (31.5 inch)
- Resolution (max.)
1920 x 1080 p
- Screen resolution
Full HD (1920 x 1080 Pixel)
- Display (cm)
80 cm
- Screen size diagonal (cm)
80 cm
- Screen size diagonal (inches)
31.5 inch
27 kWh/year
- Power consumption (off)
0.3 W
- Power consumption (ON)
27 W
- No. of DisplayPort
1 x
- No. of HDMI ports
1 x
- No. of VGA ports
1 x
- Range of uses
Home
- Display resolution mode
Full HD
- Touchscreen (display)
Yes
- Features
Touchscreen
- Panel technology
VA LED
- Brightness
425 cd/m²
- Response time
8 ms
- Hor. viewing angle
178°
- Vertical viewing angle
178°
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3308264 Iiyama 32" PCAP Anti-Glare, Bezel Free 30-Point Digital signage display EEC: F (A - G) 80 cm 31.5 inch 1920 x 1080 Pixel
User & Safety Instructions
User & Safety Instructions 3308264 Iiyama 32" PCAP Anti-Glare, Bezel Free 30-Point Digital signage display EEC: F (A - G) 80 cm 31.5 inch 1920 x 1080 Pixel
Description
The ProLite TF3215MC-B2AG is equipped with PCAP touch technology and is housed in a shapely edge-to-edge glass design, the Antiglare coated glass minimizes interfering reflections from external light sources, which can negatively affect color reproduction, contrast and picture sharpness. Thanks to its completely border-free glass surface with extraordinary scratch-resistance and durability, the device is Ideal for applications in the public area. The seamless integration with kiosk systems, as well as the achievement of the IP65 protection class for dust and water resistance, is supported by a foam seal on the device. The possibility of vertical and horizontal alignment offers flexibility with almost any installation. The TF3215MC-B2AG is the ideal solution for kiosk systems, industrial environments, control rooms and interactive multimedia applications.
Touch technology - Capacitive
This technology uses a sensor network of micro-fine wires integrated into the glass surface. If the disc is touched, electrical signals are altered and the touch position can be calculated and passed on to the controller. The glass surface of this technology is extremely durable, the touch functionality remains unaffected, even if the glass is scratched. It offers a perfect image playback and can be operated with the fingers (also with latex gloves) or magnetic pens.
Foam sealing
A foam seal (8 mm) around the monitor provides for seamless integration and optimum dust protection.
Ball drop test
During the ball drop test, a 500 gram steel ball from a height of 1.3 meters is dropped onto the touchscreen. If the surface of the touch screen remains undamaged, the screen passes the ball drop test and is characterized by high impact strength and durability.
Touch through glass
This touch-screen display with touch-through-glass function converts conventional glass surfaces in interactive touch-screens. Perfect for interactive shop windows, POS or in restaurants as digital menu
24/7
The displays are suitable for 24/7 continuous operation.
This text is machine translated.
Touch technology - Capacitive
This technology uses a sensor network of micro-fine wires integrated into the glass surface. If the disc is touched, electrical signals are altered and the touch position can be calculated and passed on to the controller. The glass surface of this technology is extremely durable, the touch functionality remains unaffected, even if the glass is scratched. It offers a perfect image playback and can be operated with the fingers (also with latex gloves) or magnetic pens.
Foam sealing
A foam seal (8 mm) around the monitor provides for seamless integration and optimum dust protection.
Ball drop test
During the ball drop test, a 500 gram steel ball from a height of 1.3 meters is dropped onto the touchscreen. If the surface of the touch screen remains undamaged, the screen passes the ball drop test and is characterized by high impact strength and durability.
Touch through glass
This touch-screen display with touch-through-glass function converts conventional glass surfaces in interactive touch-screens. Perfect for interactive shop windows, POS or in restaurants as digital menu
24/7
The displays are suitable for 24/7 continuous operation.
This text is machine translated.
Scope of delivery
- ProLite TF3215MC-B2AG
- Cable: Mains, HDMI, USB
- User manual.
Hints
HDMI is a registered trademark of HDMI Licensing, LLC. The “CI Plus” Logo is a trademark of CI Plus LLP. All information provided is subject to change without notice. Design and functions are subject to change
