IMG Stageline MPX-20USB 3-channel DJ mixer
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Mic input: 1mV
- Phono input: 9 mV
- CD input: -
- Line input: 450 mV
- Master output: 1 V
- Record output: 1 V
- Headphones:>=8 Ohm
- Frequency range 20-20000 Hz
- 0.1 % distortion factor
- Signal-to-noise ratio: 63 dB, unfinished evaluates
- Sound controller, low: -
- Sound controller, in the middle of: -
- Sound controller, High: -
- Talkover: -
- Gooseneck lamp: -
- Power supply: 5V DC current /500mAuber USB interface
- Permissible operating temperature: 0-40°C
- Dimensions: 150 x 70 x 140 mm
- Weight: 700 g
- Product type
DJ mixer
- Interfaces
Phono in
- No of. audio inputs
2 x
- Dim
(W x H x D) 150 x 70 x 140 mm
- Weight
700 g
- Principle
3-channel
- Width
150 mm
- Height
70 mm
- Depth
140 mm
- No. of RCA outputs
2 x
- No. of line-ins
2 x
Documents & Downloads
Datasheet
Datasheet 1332151 IMG Stageline MPX-20USB 3-channel DJ mixer
User & Safety Instructions
User & Safety Instructions 1332151 IMG Stageline MPX-20USB 3-channel DJ mixer
Description
Features
- 3-channel stereo DJ-mixer with USB interface. Plug 'n' mix!
- Integrated USB audio interface (will be identified and addressed as an external sound card)
- Full-duplex USB-Port (simultaneous recording and playback possible) for playback of digital audio data from the computer and for recording the mixing on the computer
- 1 microphone input channel
- 2 stereo input channels, can be switched line/phono and USB/Line/Phono
- 1 stereo output channel (Master)
- 1 stereo RECORD output
- Pre-listening (CUE) of the stereo input channels via adjustable headphone output
- Crossfader
- LED level indicator
- Robust, compact metal casing
- Power is supplied via the USB interface or optional power supply with USB connection delamar.de 11/2014 The IMG Stage Line MPX20-USB is a prop more mixer for two channels plus microphone, which combines all important functions in a confined space, the minimalist assessed DJs need. Or all that a reliable second device you need. . . As a bonus, there are even two headphone jacks. The home range makes this mixer is a good figure, if space-saving two audio signals are then cross-faded.
- This text is machine translated.
