IMG Stage Line MPX-44/SW stereo mixer

Mic input: 1.5 mV
Phono input: 3mV
CD input: 150 mV
Line input: 150 mV
Master output: 1 V/600 Ohm (Master, Booth, Zone)
Record output: 0.5 V/600 Ohm
Headphones:>=8 Ohm
Frequency range 20-20000 Hz
0.1 % distortion factor
Signal-to-noise ratio: 61 dB, unfinished evaluates
Sound controller, Depth: +12 dB, -12 dB/50 Hz (MIC) +15dB, -30 dB/50 Hz (CH 1-4)
Sound controller, the middle: +12 dB, 12 dB/1 kHz (MIC) +15dB, -30 dB/1 kHz (CH 1-4)
Sound controller, High: +12 dB, -12 dB/10 kHz (MIC) +15 dB, -30 dB/10 kHz (CH 1-4)
Talkover: -16 dB
Gooseneck lamp: 12V/5W, BNC
Power supply 230 VWechsel/50 Hz/20 VA
Permissible operating temperature: 0-40°C
Dimensions: 482 x 177 x 105 mm, 4 HE
Weight: 4 kg.

User & Safety Instructions 1332158 IMG Stageline MPX-44/SW DJ mixer

6-channel stereo DJ-mixer with black, brushed aluminum front plate
6 input channels (4 Stereo, 2 microphone way)
Stereo input channels can be switched 2 x phono/line and 2 x Line/Line, with LED level display of stereo total
Input channels with input gain controller (Gain) and 3-way tone control, stereo input channels with cue function
DJ-MIC with auto-talkover, pad-switch and on-switch
Mic with PAD switch and on-switch
Switch when illuminated in blue
Adjustable, cross-fader-controlled headphone output with preview (PFL) of the stereo input channels and Mic
Replaceable crossfader with assignment switches
Particularly smooth HQ-Fader
Master output with stereo-LED level display
Additional outputs booth and zone
Connection for gooseneck lamp GNL-200, GNL-204 or gnl-205
