IMG Stageline WAVE-12A Active PA speaker 30 cm 12 inch 200 W 1 pc(s)
EAN:
Part number:
Item no:
Highlights & Details
IMG Stageline WAVE-12A active full-range loudspeaker box, 350 W.
- RMS power:200 W
- Max. power:350 W
- 12 inch
- 119 dB
Technical specifications
- Input signal: 250 mV/7 kΩ (Line, XLR, bal.), 150 mV/16 kΩ (Line, RCA), 9.5 mV/0.8 kΩ (Mic, XLR, bal.), 9.5 mV/0.8 kΩ (Mic, 6.3 mm jack)System : 12/2-full range bass reflexWoofer : 30 cm woofer (12")Tweeter : 25 mm horn tweeter (1")Number of built-in LS chassis: 2Sound pressure 95 dB/W/mHorizontal angle of radiation 90°Vertical beam angle 60°Housing material : PlasticMounting device: M8 threaded inserts, stand sleevePower supply : ~ 230 V/50 Hz/370 VAInputs : XLR or RCA L/R (Line), XLR or 6.3 mm jack (Mic)Outputs : XLR, bal. (Parallel line-out)
- Product type
Active PA speaker
- Type
Active, wired + wireless (Bluetooth)
- RMS power
200 W
- Max. power
350 W
- Speaker size (cm)
30 cm
- Speaker size (inch)
12 inch
- Max. sound pressure
119 dB
- Interfaces
XLR out
XLR in
- Features
Bluetooth
- Dim
(W x H x D) 390 x 610 x 340 mm
- Frequency range
55 - 20 000 Hz
- Weight
16 kg
- Content
1 pc(s)
- Width
390 mm
- Height
610 mm
- Depth
340 mm
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2584170 IMG Stageline WAVE-12A Active PA speaker 30 cm 12 inch 200 W 1 pc(s)
Description
The Wave series PA speaker boxes are impressive with good sound and an attractive price. They are the ideal starting equipment for the DJ and are suitable for small to medium-sized function rooms. The modern plastic housing is also light and easy to handle, ideal for mobile use.
This text is machine translated.
This text is machine translated.
Scope of delivery
- 1x WAVE-12A active full-range loudspeaker box
