Impulse changeover switch DIN rail Finder 20.22.8.120.4000 2 makers 120 V AC 4000 VA Piece 1 pc(s)
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Impulse changeover switch
Operating voltage
120 V AC
Contact type
2 makers
Switching voltage (max.)
250 V AC
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 28.56
3
4% = € 1.24
€ 27.32
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 28.56 / piece)
€ 28.56
plus VAT.
Only 7 Piece(s) available
Technical specifications
- Function: Mechanical switch
- Installation depth: 58.4 mm
- Width in division units: 1
- Frequency of control voltage: 50 Hz - 60 Hz
- Max. Switching current (cos phi = 0.6): 12 A.
- Max. Bulb load 2000 W
- Manual operation possible: Yes
- Max. Fluorescent lamp load 1000 VA
- Max. Fluorescent lamp load (Duo-circuit): 1000 VA
- Max. Fluorescent lamp load (compensated in parallel): 750 VA
- Packaging type
Piece
- Product type
Impulse changeover switch
- Type
20.22.8.120.4000
- Operating voltage
120 V AC
- Permanent current (max.)
16 A
- Contact type
2 makers
- Contact material
AgSnO2
- Switching sequence step 1
ON-ON
- Switching sequence step 2
OFF-OFF
- Switching voltage (max.)
250 V AC
- Max. switching capacity
4000 VA
- Features
+ test button
- Mounting type
DIN rail
- Width
17.5 mm
- Depth
58.4 mm
- Dim
(W x D) 17.5 mm x 58.4 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
DIN rail
Mechanical switch
60.8 mm
1
AC
0
2
0
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2473950 Impulse changeover switch DIN rail Finder 20.22.8.120.4000 2 makers 120 V AC 4000 VA Piece 1 pc(s)
Description
Surge current switch for 35 mm rail, 2 NO contacts for 16 A / 250 V AC, contact material AgSnO2, max. switching power at 230 V AC: AC1 4000 VA, AC15 750 VA, glow and halogen lamps 2000 W, compensated fluorescent lamps 750 W, uncompensated fluorescent lamps 1000 W, energy saving lamps 400 W, LED (230 V AC) 400 W, LV halogen lamps or LED with EVG 400 W, LV halogen lamps or LED with KVG 800 W. Coil data 120 V AC, 6.5 VA, 680 Ohm, width 17.5 mm, switching sequence: On / off, test button and mechanical switch position indicator, relay protection type: IP 20
