Intellinet 720922 24 ports Patch panel 483 mm (19") CAT 6A 0.5 U Black Equipped
EAN:
Part number:
Item no:
INTELLINET 24-Port Cat6a patch panel shielded FTP 19" 0.5 HE terminal strips with 90 degree angled cable entries black
Highlights & Details
- Contacts coated with at least 3 μm gold for maximum connection quality of your network cables
- Terminal strips with 90 degree angled cable entries for easy installation
- Suitable for Krone LSA+ insertion tools
- Suitable for wire and solid wire cables from 23 to 26 AWG
- Suitable for shielded Cat6a network cable (FTP)
Technical specifications
- Product type
Patch panel
- Rack size
483 mm (19")
CAT 6A
- Rack unit
0.5 U
- Transfer rate
1 GBit/s
- Port
24 ports
- Patch panel design
Equipped
- Width
482 mm
- Height
22 mm
- Factory colour
Black
- Length
107 mm
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2270500 Intellinet 720922 24 ports Patch panel 483 mm (19") CAT 6A 0.5 U Black Equipped
Description
Patch panels form the backbone of your network – with this shielded 24-port Cat6a patch panel from INTELLINET Network Solutions you can trust in the highest quality and reliability. Due to its design of only half a height unit, its space requirements in your network cabinet are minimal. Strong shielding and contacts coated with 3 μm gold ensure maximum signal integrity. A grounding cable is included in the delivery.
This text is machine translated.
This text is machine translated.
Features
- IEEE 802.3 (10Base-T Ethernet)
- IEEE 802.3u (100Base-TX Fast Ethernet)
- IEEE 802.3ab (1000Base-T Gigabit Ethernet)
- ISO/IEC 11801
- ANSI/TIA
- 568 A/B color-coded
- Operating temperature: 10 – 60°C
- Humidity: 10% – 90% RH, non-condensing
- Storage temperature: -40 – 70°C.
Scope of delivery
- 24-port Cat6a patch panel, shielded
- PG cable
- Quick guide
