Intercable AP60-2 Cordless hydraulic punch press 3 Ah Li-ion incl. rechargeables
EAN:
Part number:
Item no:
Highlights & Details
Intercable AP60-2 Cordless hydraulic punch press 3 Ah Li-ion incl. rechargeables
- /3 Ah Li-ion battery
Technical specifications
- Product type
Cordless hydraulic punch press
- Capacity (mAh, Ah)
3 Ah
- Technology
Li-ion
- No. of power packs included
1
- Features
incl. rechargeables
- Length
334 mm
- Suitable for
Connector
- max. cross section
300 mm²
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2573148 Intercable AP60-2 Cordless hydraulic punch press 3 Ah Li-ion incl. rechargeables
Description
Suitable for crimping aluminum and copper cables up to 300 qmm, 3 years warranty (20,000 cycles), light, compact and robust design, housing in glass fiber reinforced, impact-resistant plastic, foldable press head up to 340 degrees, rotatable double piston technology enables a fast feed and cycle time, ergonomic, well balanced 2-component grip enables fatigue-free working with one-hand operation, 2-stage speed advantageous when positioning the device at the cable lug/connector, opening of the device in any position by means of left/right-acting push button, LED for illuminating the working area of powerful rechargeable battery, approx. 250 crimping operations at 150 qmm Cu, charging time: 50 min., max. stroke 17mm, pressing force 60kN, operating pressure 700 bar (70MPa), set-fitting: Hydraulic battery press, LI-Ion battery 18V/3AH (RA11), shoulder strap (TG2), charger for LI-Ion batteries 18V/230V (LG8), carry bag
