Jäger Direkt Stuttgart2 Industrial power distributor BAVEV60/3353 400 V 63 A
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Terminal distribution cabinet
- Stuttgart2, all-current sensitive
Technical specifications
- Product type
Industrial power distributor
- Nominal input voltage
400 V
- Nominal input current
63 A
- Nominal output voltage
400 V
- Inputs
Terminal 35 mm²
- Type A
Screw terminals
- Outputs
Each 1 CEE-socket 63 A and 32 A, 5polig · 2 CEE-Sockets 16 A, 5polig · 6 protective contact sockets 16 A
- Type B
CEE connector (5-pin, 16 A)
CEE connector (5-pin, 32 A)
CEE connector (5-pin, 63 A)
PG connector
- No. of CEE connectors
4
- No. of PG sockets
6
IP44
- Factory colour
Orange
- Dim
(W x H x D) 670 x 1200 x 360 mm
- Width
670 mm
- Height
1200 mm
- Depth
360 mm
- Weight
50 kg
- Inputs (CEE power distributor)
Screw terminals
- Outputs (CEE power distributors)
CEE connector (5-pin, 16 A)
CEE connector (5-pin, 32 A)
CEE connector (5-pin, 63 A)
PG connector
- Number of pins
5
Documents & Downloads
Datasheet
Datasheet 2344786 Jäger Direkt Stuttgart2 Industrial power distributor BAVEV60/3353 400 V 63 A
Description
connection-distributor-End cabinet Stuttgart 2 is a combination of connection and distributor-End cabinet. This can be connected to a distributor in public supply network.
This text is machine translated.
This text is machine translated.
Features
- 2 FI, 63 A (0.03 and 0.5) with counter field.
Hints
Please note: This part is an order-related production. Unfortunately, this is why it is not possible to return the goods.
