Jamicon Electrolytic capacitor Radial lead 10 mm 4.700 µF 50 V DC 20 % (Ø x H) 22 mm x 40.0 mm 1 pc(s) Piece
Part number:
Item no:
Packaging type
Piece
Product type
Electrolytic capacitor
Type
Radial lead
Capacity (elec.)
4.700 µF
Nominal voltage
50 V DC
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 2.51
10
7% = € 0.18
€ 2.33
25
10% = € 0.26
€ 2.25
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 2.51 / piece)
€ 2.51
plus VAT.
Highlights & Details
Jamicon electrolytic capacitor 4700UF 50V 22X40mm
Our service for you
Technical specifications
- ESD Packaging: No ESD
- Series LP
- Design_1: Radial
- Applications: Recommended applications: Smoothing circuit, TV/monitor, adapter, SMPS
- Technology: Aluminium electrolytic capacitor
- Mounting type_1: Snap-in
- Delivery form_1: Loose
- Connections_1: 2-pin
- Properties_1: Operating temperature of up to 105 °C.
- 1,000 hours battery life
- Pitch_1:10 mm
- Capacity 4,700 µF
- Capacity_1: 4,700
- Unit of capacity: µF
- Capacity Tolerance 20%
- Loss factor tan δ: 0.3
- Apparent resistance 4 Ohm
- Nominal voltage DC 50 V
- Lifetime_1: 2,000 h
- Packaging type
Piece
- Product type
Electrolytic capacitor
- Type
Radial lead
- CS
10 mm
- Dim
(Ø x H) 22 mm x 40.0 mm
- Capacity (elec.)
4.700 µF
- Nominal voltage
50 V DC
- Tolerance ±
20 %
- Height
40.0 mm
- (Ø)
22 mm
- Content
1 pc(s)
- Material
Aluminium
- Width
22 mm
- Length
40.0 mm
- RoHS-compliant
Yes
- Max. temperature
105 °C
- Type
TLP478M050S1A5Q40L
Documents & Downloads
Datasheet
Datasheet 3527506 Jamicon Electrolytic capacitor Radial lead 10 mm 4.700 µF 50 V DC 20 % (Ø x H) 22 mm x 40.0 mm 1 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 3527506 Jamicon Electrolytic capacitor Radial lead 10 mm 4.700 µF 50 V DC 20 % (Ø x H) 22 mm x 40.0 mm 1 pc(s) Piece
Description
Jamicon flat cup electrolytic capacitors snap-in RM10
