Name: JBC Tools D530014 Desoldering tip Content 1 pc(s)
Brand: JBC Tools
SKU: 3780654

Technical diagram of a connector pin tip, showing allowable dimensions and tolerances: diameter 0.4 mm max (0.016 in) and pin length/shape measurements in millimeters and inches.

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Type/inner-Ø D530014/0.8 mm
Outside diameter 2.5 mm
Application: Pin cleaning

Product type: Desoldering tip

Compatible with: JBC

Type: D530014

UKCA: not relevant

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 3780654 JBC Tools D530014 Desoldering tip Content 1 pc(s)

Description

This assortment includes many shapes and sizes for different applications. Features: For use with the DT530-A angled desoldering iron, ensure a small distance between the pin and the tip hole, optimal air intake and easy running cleaning. 1 desoldering tip supplied. Selection criteria: Type/inner-Ø: D530014/0.8 mm outer-Ø: 2.5 mm Application: Pincleaning Product number: JBC-D530014 Shop number: 812825 EAN: 8427327632615
