Jonsbo TK-5 Midi tower PC casing White Window
EAN:
Part number:
Item no:
Highlights & Details
Jonsbo TK-5 Midi tower PC casing
- White Midi-Tower with panoramic glass design
- Numerous fans and radiator locations for an effective cooling power
- Motherboards to ATX
- Space for graphics cards up to 460 mm and CPU-cooler with a height of up to 180 mm
Technical specifications
- Max. CPU-cooler height 180 mm
- Max. Graphics card length 460 mm
- Max. Power supply length / depth 220 mm
- PSU format ATX
- Power supply position: Rear down
- Fan slots (base): 120mm fan (3x), 140mm fan (3x)
- Fan slots (rear): 120mm fan (1x)
- Fan slots (side): 120mm fan (3x)
- Fan slots (cover): 120mm fan (3x), 140mm fan (3x)
- Max. Number of fans: 10
- Max. Radiator compatibility 2x Triple (360 mm).
- Radiator-/AiO-Support (Ground): 360mm-Radiator
- Radiator-/AiO-Support (lid): 360mm-Radiator
- Expansion / PCI slots: 7
- Materials: Steel, tempered glass / hard glass
- Product type
PC casing
- Case type
Midi tower
- Factory colour
White
- Interfaces (front)
Audio line in
Audio line out
USB type A
USB C®
- 6.4 cm (2.5") internal slots
2
- 8.9 cm (3.5") internal slots
4
- Width
245 mm
- Height
539 mm
- Depth
474 mm
- Weight
10400 g
- Form factor
ATX
Micro-ATX
Mini-ITX
- No. of USB type A 3.0 ports
2 x
- No. of USB 3.0 ports
1 x
- Wireless charging
No
- Dim
(W x H x D) 245 x 539 x 474 mm
- Features
Window
- No. of USB 3.2
2 x
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3776393 Jonsbo TK-5 Midi tower PC casing White Window
Description
With the Jonsbo TK-5 your gaming setup becomes a real eyecatcher. Thanks to the open design you have a full view of your built-in hardware.
Jonsbo TK-5: PC-casing with panorama design
The Jonsbo TK-5 Midi-Tower offers the perfect balance between size and functionality. With plenty of space for powerful hardware and efficient cooling, it is the ideal choice for gaming builds.
Extensive cooling options with fans and radiators
In order to cool your hardware at every load, up to ten fans can be fitted simultaneously in the Jonsbo TK-5. Thereby, the casing offers space at the lid and the floor for three 120- or 140-mm fans. Laterally you can install three large 120 mm fans, behind one.
AiO water cooling is also easy to install, if you want to cool your high performance hardware with water cooling. For a 360 mm water cooling there is space on the lid and the floor.
Install your hardware
The housing offers enough space for high-performance gaming hardware. It supports the installation of long graphic cards up to 460 mm. The CPU cooler should not exceed a height of 180 mm. In order to store programs and games, a total of eight drives can be installed.
This text is machine translated.
Jonsbo TK-5: PC-casing with panorama design
The Jonsbo TK-5 Midi-Tower offers the perfect balance between size and functionality. With plenty of space for powerful hardware and efficient cooling, it is the ideal choice for gaming builds.
Extensive cooling options with fans and radiators
In order to cool your hardware at every load, up to ten fans can be fitted simultaneously in the Jonsbo TK-5. Thereby, the casing offers space at the lid and the floor for three 120- or 140-mm fans. Laterally you can install three large 120 mm fans, behind one.
AiO water cooling is also easy to install, if you want to cool your high performance hardware with water cooling. For a 360 mm water cooling there is space on the lid and the floor.
Install your hardware
The housing offers enough space for high-performance gaming hardware. It supports the installation of long graphic cards up to 460 mm. The CPU cooler should not exceed a height of 180 mm. In order to store programs and games, a total of eight drives can be installed.
This text is machine translated.
Features
- Midi-Tower in white
- Up to 10 fans
- Space for radiators up to 360 mm
- Motherboards to ATX
- GPU up to 460 mm and CPU-cooler up to 180 mm high
- Up to eight drives
Hints
Please pay attention to the compatibility information of the manufacturer. You can find an up-to-date overview on the manufacturer's website.
