Joy-it ARD_MEGA2560R3 Compatible board Arduino MEGA 2560R3 Atmel AVR
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 18.48 / piece)
€ 18.48
plus VAT.
Highlights & Details
Joy IT Mega 2560 R3
- No driver for Linux or Mac needed
- Option to show the Uno like a keyboard, mouse, joystick etc.
Technical specifications
- ATmega2560 microcontroller
- SRAM: 8 kB
- EEPROM: 4 kB
- 16 MHz clock speed
- Type
Arduino Mega
- Processor
ATmega2560
8 kB
- Clock speed
16 MHz
- Memory type
SRAM
- Memory capacity
4 kB
- Length
101.52 mm
- Width
53.3 mm
- Product type
Compatible board
- MC layout
AVR
- Interfaces
USB
Power strip
- Series
Atmel AVR
- Technology
8-bit MCU
- Tool type
Development kit
- No. of digital inputs
16
- No. of analogue inputs
15
- No. of digital inputs
54
- No. of digital outputs
54
- I/O number
54
- Type
ATmega2560
- EEPROM
4 kB
- Operating voltage
5 V DC
- Digital inputs
54 (15 for PWM output can be used)
- Current consumption
40 mA
Documents & Downloads
Datasheet
Datasheet 1409778 Joy-it ARD_MEGA2560R3 Compatible board Arduino MEGA 2560R3 Atmel AVR
User & Safety Instructions
User & Safety Instructions 1409778 Joy-it ARD_MEGA2560R3 Compatible board Arduino MEGA 2560R3 Atmel AVR
Description
The Mega Board is the right microcontroller board for those who want to enter the programming world quickly and easily.
On the Internet you will find a variety of tutorials and instructions on the above-mentioned micro-controller board that will give you an easy introduction to the world of programming.
Its ATmega2560 microcontroller provides you with enough power for your ideas and projects. It is 101.52 mm x 53.3 mm in size and has many connection possibilities with 54 digital inputs and outputs and 16 analogue inputs.
No drivers are needed for Linux or Mac (inf-file for Windows and included in the Arduino IDE), and the possibility to show the Uno like a keyboard, mouse, joystick etc.
The MEGA2560 R3 now also has SDA and SCL pins next to the AREF. Moreover, it has two new pins in the proximity of the reset pin. One of them is an IOREF that allows the shields to take over the tension of the board
