Joy-it Button22NA-02 Button22NA-02 Kill button 220 V latch Red , Green (Ø x L) 22 mm x 46.50 mm IP67, IK10 1 pc(s) Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Kill button
Lighting type
LED
Connection
Socket
Switching voltage
220 V
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 21.18
3
4% = € 0.93
€ 20.25
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 21.18 / piece)
€ 21.18
plus VAT.
14-day return policy included
Highlights & Details
Emergency Stop Switch, Stainless Steel, Resting, LED Green/Red, Emergency Stop, 220 V
- 220 VStainless steel2 LED colors, green/redIP67IK10PA66Mechanical locking mechanism (rotation)Snap-in
Technical specifications
- Kern and outer material: Stainless steelMaterial of the pins: H65 silver-/gold-coatedButton depth 3 mmDimensions of mounting hole Ø 22 x ≤7.5 mmOverall dimensions Ø 21.9 x 46.5 mmLED life 40 000 hoursConnections: 1x NO, 1x NCInsulation resistance ≥ 1000 MΩBreakdown voltage 1000 V AC min.Contact resistance ≤ 50 mΩTorque nut 5 - 14 NmSocket material PA66 flame-retardantAmbient temperature -30 to 80°C.
- Packaging type
Piece
- Product type
Kill button
- Switch/button features
illuminable
Front ring (steel)
for emergency power-off
- Casing/button colour
Red
- Functions
latch
- Lighting type
LED
- Colour
Red
Green
- Bulb type
LED (monochrome)
- Print motif
EMERGENCY STOP
- Material
Steel
- Connection
Socket
- Contact resistance
50 mΩ
- Switching voltage
220 V
- Min. temperature
-30 °C
- Max. temperature
80 °C
- Length
46.50 mm
- Width
21.9 mm
- (Ø)
22 mm
- Button diameter
27 mm
- Recess diameter
21.90 mm
- Recess depth
7.5 mm
- Recess width
22 mm
- Front panel cut-out
Ø 22 x ≤7.5 mm
IP67
IK10
- Content
1 pc(s)
- Insulation resistance
1000 MΩ
- Dim
(Ø x L) 22 mm x 46.50 mm
- Industrial packaging
Yes
- Board thickness (max.)
7.5 mm
- Type
Button22NA-02
Documents & Downloads
Datasheet
Datasheet 2757881 Joy-it Button22NA-02 Button22NA-02 Kill button 220 V latch Red , Green (Ø x L) 22 mm x 46.50 mm IP67, IK10 1 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 2757881 Joy-it Button22NA-02 Button22NA-02 Kill button 220 V latch Red , Green (Ø x L) 22 mm x 46.50 mm IP67, IK10 1 pc(s) Piece
Description
Our locking emergency-off steel button impresses through high-quality materials, protection classes and ergonomics. It is made of stainless steel and meets the protection classes IP67 (dust and water), IK10 (impact) and PA66 (flame). Our steel pushbutton is suitable for many applications because of its protection classes, large temperature range and long service life. The steel button has a bright LED ring that can be lit in two different colors (red & green). This is used to identify whether the emergency stop button has already been made or not. When the emergency stop is pressed, the button locks into place. This can be released for you by rotating the button again. The required connection cables, bushing, sealing ring and nut are included in the delivery.
This text is machine translated.
This text is machine translated.
Hints
Re switch position: content in parentheses describes the n/o and n/c contact constellation
