JYA-NAY JN09B471KY12N+DL25MM Suppression capacitor Radial lead 470 pF 440 V AC 10 % 1 pc(s)
Part number:
Item no:
Product type
Suppression capacitor
Type
Radial lead
Capacity (elec.)
470 pF
Tolerance ±
10 %
Max. temperature
125 °C
Datasheet (PDF)
Highlights & Details
JYA-NAY suppression capacitor 470pF X1/Y1 RM12.5
Our service for you
Technical specifications
- ESD Packaging: No ESD
- Series JN
- Approvals: TÜV, ENEC, cULus, CQC
- Design_1: Radial
- Ceramic type Y5P
- Technology: Ceramic noise suppression capacitor
- Mounting type_1: THT
- Delivery form_1: Loose
- Connections_1: 2-pin
- PROPERTIES_1: NOMINAL VOLTAGE (50/60HZ): X1 440V AC (UL/CSA 250V AC); Y1 250V AC
- Minimum insulation coating of 0.4mm
- Flame-retardant coating according to UL94-0
- High operating temperature of 125 °C (UL/CSA: 85 °C)
- Disk thickness 6 mm
- 9 mm disc diameter
- Wire diameter 0.6 mm.
- Pitch_1:12.5 mm
- Climate category IEC 25/125/21
- Capacity 470 pF
- Capacity_1: 470
- Unit of capacity: PF
- Capacity Tolerance 10%
- Dielectric Y5P
- Nominal voltage AC 440 V
- Class X1/Y1
- Insulation resistance_1: 10 ohms
- Product type
Suppression capacitor
- Type
Radial lead
- Capacity (elec.)
470 pF
- Nominal voltage
440 V AC
- Tolerance ±
10 %
- (Ø)
9 mm
- CS
12.5 mm
- Material
Ceramic
- Max. temperature
125 °C
- Content
1 pc(s)
- Dim
(Ø) 9 mm
- RoHS-compliant
Yes
- Type
JN09B471KY12N+DL25MM
- Operating temperature (max.)
125 °C
- Operating temperature (min.)
-25 °C
- Certification marks
UL 60384-14 IEC/EN 60384-14 2013, EN 60384-14 2013, IEC EN 60384-14
Documents & Downloads
Datasheet
Datasheet 3463018 JYA-NAY JN09B471KY12N+DL25MM Suppression capacitor Radial lead 470 pF 440 V AC 10 % 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3463018 JYA-NAY JN09B471KY12N+DL25MM Suppression capacitor Radial lead 470 pF 440 V AC 10 % 1 pc(s)
Description
Ceramic noise suppression capacitors X1,Y1
