Kabeltronik 060105008 Strand LiYv 1 x 0.50 mm² Red 100 m
EAN:
Part number:
Item no:
Product type
Strand
No. of leads
1 x
Cross section (each core)
0.50 mm²
Cable type
LiYv
Outside Ø
1.80 mm
Datasheet (PDF)
Number
Total (1 m = € 0.33)
€ 32.76
plus VAT.
Only 7 Set(s) available
Highlights & Details
LiYv 0,50 qmm red, Hook-up wire , stranded, PVC
- 100 metre
Technical specifications
- Insulation resistance: min. 200MOhm x km at +20°C
- Operating voltage: max. 900V
- Testing voltage: 2500V
- Temperature range: static: -30°C to +70°C dynamic:-5°C to +70°C
- Bending radius: static: min. 10 x O.D. dynamic: min. 12 x O.D.
- Product type
Strand
- No. of leads
1 x
- Content
100 m
- Cross section (each core)
0.50 mm²
- Insulation material
PVC
- Cable features
Flexible
- Cable type
LiYv
- Outside Ø
1.80 mm
- Nominal voltage
900 V
- Packaged
Yes
- Halogen-free
No
- Manufacturer part #
060105008
- Factory colour
Red
- Core layout
Copper wire
- Core layout
16 x 0.20 mm
- Material (details)
Insulation: PVC according to VDE 0207
- Sold per metre
No
- Cross section
1 x 0.50 mm²
- Max. temperature range (flexible installation)
+70 °C
- Min. temperature range (flexible installation)
-30 °C
- Max. temperature range (fixed installation)
+70 °C
- Min. temperature range (fixed installation)
-30 °C
- Type
LiYv
Documents & Downloads
Datasheet
Datasheet 323548 Kabeltronik 060105008 Strand LiYv 1 x 0.50 mm² Red 100 m
User & Safety Instructions
User & Safety Instructions 323548 Kabeltronik 060105008 Strand LiYv 1 x 0.50 mm² Red 100 m
Description
Conductor: tinned stranded copper wire · Insulation: PVC acc. to VDE 0207
Scope of delivery
- Coil (100 m).
- This text is machine translated.
Hints
Not allowed for power current outside any equipment!
