Kabeltronik 65H240000 Speaker cable L-RF 2 x 4 mm² Black 100 m
Part number:
Item no:
Product type
Speaker cable
Cable type
L-RF
No. of leads
2 x
Cross section (each core)
4 mm²
Content
100 m
Datasheet (PDF)
Technical specifications
- Type: Multi-conductor cables
- Weight kg/km: 180.00 kg/km.
- CU weight kg/km: 76.80 kg/km.
- Use: Loudspeaker cable halogen-free, flame resistant (FRNC) for fixed laying in studios, stadiums and other safety-relevant building areas.
- Conductor material: Cu-strand, BLK.
- Sheath material: FRNC
- Product type
Speaker cable
- Cable type
L-RF
- No. of leads
2 x
- Cross section (each core)
4 mm²
- Cross section
2 x 4 mm²
- Cable features
Unshielded
Flame-retardant
- Outside Ø
10 mm
- Factory colour
Black
- Content
100 m
- Nominal voltage
500 V
- Test voltage
2500 V
- Bend radius (no. of ODs for fixed installation)
15
- Halogen-free
Yes
- Shielded
No
- Manufacturer part #
65H240000
- Insulation material
FRNC
- Min. temperature range (fixed installation)
-20 °C
- Max. temperature range (fixed installation)
+70 °C
- Min. temperature range (flexible installation)
-5 °C
- Max. temperature range (flexible installation)
+70 °C
- Core layout
56 x 0.30 mm
- Type
L-RF 2 x 4,00 qmm, schwarz
Documents & Downloads
Datasheet
Datasheet 3805093 Kabeltronik 65H240000 Speaker cable L-RF 2 x 4 mm² Black 100 m
User & Safety Instructions
User & Safety Instructions 3805093 Kabeltronik 65H240000 Speaker cable L-RF 2 x 4 mm² Black 100 m
Description
Speaker cable halogen-free, flame resistant (FRNC) for fixed installation in studios, stadiums and other safety-relevant building areas.
