Keithley 6485/E Bench multimeter
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 4,189.08 / piece)
€ 4,189.08
plus VAT.
Highlights & Details
6485/E
- Up to 1000 measured values per second.
- Integrated Emulation Mode Model 485
- IEEE-488 and RS-232 interfaces
- Analogue output.
- Jet and radiation monitoring, SEM-beam current measurement
- Leakage current testing on insulators, switches, relays and other components
- Testing and characterization of opto-electronic components
- Alignment of optical fibers
- Characterization of sensors
- I-V-measurement of semiconductors and other components
Technical specifications
- Resolution 5.5 digits
- Current measuring range DC 0A -20mA (measuring accuracy ±0.04% + 400 fA)
- Reading speeds of up to 1000 measurements/second
- GPIB, RS232, USB
- Product type
Bench multimeter
- Height
90 mm
- Width
214 mm
- Weight
2.8 kg
Manufacturer's standards (no certificate)
- Type
6485/E
- Dim
(W x H) 214 mm x 90 mm
Documents & Downloads
Datasheet
Datasheet 1164922 Keithley 6485/E Bench multimeter
User & Safety Instructions
User & Safety Instructions 1164922 Keithley 6485/E Bench multimeter
Description
The 5-1/2-digit pico ammeter 6485 combines technical expertise in the area of keithley sensitive measuring instruments with improved speed and more robust design. The affordable device offers eight current measuring ranges with fast automatic range setting and is suitable for the measurement of currents 20 fA to 20 mA can be used, whereby measurement speeds of up to 1000 measurements/second can be achieved.
This text is machine translated.
This text is machine translated.
Scope of delivery
- Power cord
- User-book
- Data sheet
- Model CAP-18
- 4801
- Excel Linx
- Shield/cap and low-noise BNC cable 1.2m
