Keithley DMM7510 Bench multimeter Digital CAT II 300 V Display (counts): 10000000
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 6,147.06 / piece)
€ 6,147.06
plus VAT.
Highlights & Details
DMM7510
- CAT II 300 V
Technical specifications
- Voltage reading range DC (min.)
0.00000001 V
- Product type
Bench multimeter
- Voltage DC reading range (max.)
1010 V
- V AC reading range (min.)
0.0000001 V
- V AC reading range (max.)
707 V
- Amperage reading range DC (min.)
1 pA
- A DC reading range (max.)
10 A
- A AC reading range (min.)
1 nA
- Amperage reading range AC (max.)
10 A
- Reading range - resistance
ΜΩ 0.1 - 1 GΩ
- Reading range - capacity
0.1 pF - 1.2 mF
- Frequency reading range
3 Hz - 500 kHz
- DC resistance
10 MΩ
- AC resistance
1 MΩ
- Measurement type (details)
True RMS
- Frequency range
3 Hz - 300 kHz
- Interfaces
USB 2.0
GPIB
1x LAN (10/100 Mbps)
- Height
106 mm
- Width
255 mm
- Length
425 mm
- Weight
4500 g
Manufacturer's standards (no certificate)
- Reading category
CAT II 300 V
- Voltage metering
AC/DC
- Current reading
AC/DC
- Type
DMM7510
- Display
Digital
- Display (counts)
10000000
- Dim
(L x W x H) 425 x 255 x 106 mm
- Temperature reading range (max.)
+1820 °C
- Temperature reading range (min.)
-200 °C
- Interfaces
USB
GPIB
LAN
Documents & Downloads
Datasheet
Datasheet 1303068 Keithley DMM7510 Bench multimeter Digital CAT II 300 V Display (counts): 10000000
User & Safety Instructions
User & Safety Instructions 1303068 Keithley DMM7510 Bench multimeter Digital CAT II 300 V Display (counts): 10000000
Information
Information 1303068 Keithley DMM7510 Bench multimeter Digital CAT II 300 V Display (counts): 10000000
Description
The model DMM7510 from keithley is the first digital multimeter with touch screen on the market. The high-resolution display offers numerous graphical display and analysis options, which in many cases the additional use of a PC's superfluous. Intuitive operation with icon-based menu navigation and context-specific help reduces the learning curve and leads more quickly to reliable results. With 17 built-in functions is the model DMM7510 can be used in various ways. A resolution of 18 bits and a sampling rate of 1 MHz are unique specifications of a digitizer for digital multimeters. With a resolution of 7.5 points and an accuracy of 14 ppm is sufficient for the device highest measurement requirements. In addition to the ideal use on the working table, due to the high test speed and numerous PC interfaces (LXI/LAN, GPIB, USB) also excellent possibilities in automated tests.
This text is machine translated.
This text is machine translated.
Features
- 7.5 points
- Digitizer with a resolution of 18 bits and a sampling rate of 1 MHz
- 14 ppm basic accuracy
- Data visualization and analysis in the device
- High resolution of 1 pA for current, voltage and 100 nΩ of 10 nV for resistance measurement
- Current measurement up to 10 A
- Memory for up to 27.5 million measured values
- PC interfaces for LXI/LAN, GPIB, USB.
