Kemet 1 pc(s) MKP suppression capacitor Radial lead 1 µF 560 V DC, 275 V AC 20 % 22.5 mm (L x W x H) 26.5 x 11.0 x 20.0
Part number:
Item no:
Packaging type
Bulk
Product type
MKP suppression capacitor
Type
Radial lead
Capacity (elec.)
1 µF
Nominal voltage
560 V DC
275 V AC
Datasheet (PDF)
Technical specifications
- Series R46
- Approvals: ENEC03, cULus, CQC
- Design_1: Radial
- Applications: Class X2 radio interference suppression applications for use in electromagnetic interference (EMI) suppression in cross-line applications requiring X2 safety classification. VIntended for use in situations where a capacitor failure would not result in an electrical shock. Not for use in "series connection with mains" applications.
- Mounting type_1: THT
- Delivery form_1: Loose
- Connections_1: 2-pin
- Properties_1: • Winding technology, class X2
- • Polypropylenfolie dielectric, coating: Vacuum-metallized
- • Flame-retardant plastic casing (UL94V-0) with resin cast, no impregnation
- • damping arm
- • Low loss factor
- • High pulse load (dV/dt)
- • High insulation resistance
- Wire diameter 0.8 mm.
- Pitch_1:22.5 mm
- Climate category IEC 40/110/56
- Capacity 1 µF
- Capacity_1: 1
- Unit of capacity: µF
- Capacity Tolerance 20%
- Dielectric: Metallized PP film
- Nominal voltage DC 560 V
- Nominal voltage AC 275 V
- Pulse load 200 V/µs
- Class X2
- Packaging type
Bulk
- Product type
MKP suppression capacitor
- Type
Radial lead
- Dim
(L x W x H) 26.5 x 11.0 x 20.0 mm
- Capacity (elec.)
1 µF
- Nominal voltage
560 V DC
275 V AC
- Tolerance ±
20 %
- Material
Polypropylene
- Connection
THT
- Length
26.5 mm
- Width
11.0 mm
- Height
20.0 mm
- CS
22.5 mm
- Min. temperature
-40 °C
- Max. temperature
110 °C
- Content
1 pc(s)
- Cable Ø
0.8 mm
- RoHS-compliant
Yes
- Type
R46KN410000N1M
- Operating temperature (max.)
110 °C
- Operating temperature (min.)
40 °C
- Certification marks
EN/IEC 60384-14, UL 60384-14, CAN/CSA E60384-14
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3463037 Kemet 1 pc(s) MKP suppression capacitor Radial lead 1 µF 560 V DC, 275 V AC 20 % 22.5 mm (L x W x H) 26.5 x 11.0 x 20.0
User & Safety Instructions
User & Safety Instructions 3463037 Kemet 1 pc(s) MKP suppression capacitor Radial lead 1 µF 560 V DC, 275 V AC 20 % 22.5 mm (L x W x H) 26.5 x 11.0 x 20.0
Description
MKP suppression capacitors class X2 2
