Kemet Electrolytic capacitor Radial lead 10 mm 330 µF 250 V 20 % (Ø x H) 22 mm x 30.0 mm 1 pc(s) Piece
Part number:
Item no:
Packaging type
Piece
Product type
Electrolytic capacitor
Type
Radial lead
Capacity (elec.)
330 µF
Nominal voltage
250 V
Datasheet (PDF)
Highlights & Details
Kemet Elko 330uF 250V 22x30mm
Our service for you
Technical specifications
- ESD Packaging: No ESD
- EH series
- Design_1: Radial
- Applications: Typical applications: Power supply for general purposes, electronics, UPS, SMPS and battery chargers
- Technology: Aluminium electrolytic capacitor
- Mounting type_1: Snap-in
- Delivery form_1: Loose
- Connections_1: 2-pin
- Properties_1: Suitable for high-quality, highly reliable applications
- Niedrige Impedanz.
- Operating temperature of up to 85 °C.
- 2,000 hours battery life
- RoHS compliant and lead free
- Pitch_1:10 mm
- Capacity 330 µF
- Capacity_1: 330
- Unit of capacity: µF
- Capacity Tolerance 20%
- Loss factor tan δ: 15
- Leakage current 3,000 µA
- Nominal voltage DC 250 V
- Lifetime_1: 2,000 h
- Packaging type
Piece
- Product type
Electrolytic capacitor
- Type
Radial lead
- CS
10 mm
- Dim
(Ø x H) 22 mm x 30.0 mm
- Capacity (elec.)
330 µF
- Nominal voltage
250 V
- Tolerance ±
20 %
- Height
30.0 mm
- (Ø)
22 mm
- Content
1 pc(s)
- Material
Aluminium
- Width
22 mm
- Length
30.0 mm
- RoHS-compliant
Yes
- Max. temperature
85 °C
- Type
ELH337M250AQ2AA
- Operating temperature (max.)
85 °C
- Operating temperature (min.)
-25 °C
Documents & Downloads
Datasheet
Datasheet 3463031 Kemet Electrolytic capacitor Radial lead 10 mm 330 µF 250 V 20 % (Ø x H) 22 mm x 30.0 mm 1 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 3463031 Kemet Electrolytic capacitor Radial lead 10 mm 330 µF 250 V 20 % (Ø x H) 22 mm x 30.0 mm 1 pc(s) Piece
Description
Arcotronics flat cup electrolytic capacitors Snap-in RM
