Name: Kemet R49AI24700001M MKP suppression capacitor Radial lead 47 nF 310 V AC 20 % 1 pc(s) Bulk
Brand: Kemet
SKU: 3463054

Packaging type

Bulk

Product type

MKP suppression capacitor

Type

Radial lead

Connection

Pins

Capacity (elec.)

47 nF

Datasheet (PDF)

Unavailable

Sales and shipping:

Highlights & Details

Kemet MKP-suppression capacitor 47nF 310V RM15

ESD packing ESD
Series: R49
Approvals: CULus,ENEC
Design_1: Radial
Applications: Class X1 Radio interference suppression applications for use as electromagnetic interference (EMI) suppression filters in cross-line applications are required with safety classification X1. Intended for use in situations where shock is not possible in the event of a capacitor failure. Not for use in "series connection with mains" applications. X1-classified capacitors are only intended for use in a permanently connected device with a connection
Power cables that cannot be loosened without tools.
Mounting type_1: THT
Delivery form_1: Loose
Connections_1: 2-pin
Properties_1: Winding technology, class X1
Dielectric made of polypropylene foil, coating: Vacuum metallized
Tin-plated connections
Flame-retardant plastic housing (UL94V-0) with an resin cast
damping arm
Low loss factor (tan d)
High impulse load capacity (DU/DT)
High insulation resistance
No impregnation
Wire diameter 0.6 mm.
Pitch_1:15.0 mm
Climate category IEC 40/110/56
Capacitance 47 nF
Capacity_1: 47
Capacitance unit: NF
Capacity Tolerance 20%
Dielectric: Metallized PP film
Nominal voltage AC 310 V
Pulse load 500 V/µs
Class X1
Insulation resistance_1: 100,000 MOhm
