Kemet T495X337K010ATE100 Tantalum capacitor SMD 330 µF 10 V 10 % (L x W x H) 7.3 x 4.3 x 4.1 mm 1 pc(s) #####Tape and Re
Part number:
Item no:
Packaging type
#####Tape and Reel
Product type
Tantalum capacitor
Type
SMD
Capacity (elec.)
330 µF
Nominal voltage
10 V
Datasheet (PDF)
Technical specifications
- ESD Packaging: No ESD
- Series:T495
- Solder option 250° for 30 s.
- Design_1: X
- Applications: Typical applications include decoupling and filtering in many end applications, such as DC/DC converters, portable electronics, telecommunications, and control units that require high power ripple.
- Ceramic type: Tantalum
- Technology: Tantalum capacitor
- Mounting type_1: SMD
- Delivery form_1: Taped
- Characteristics_1: Meets or exceeds EIA standard 535BAAC
- Tape & Reel standard packaging in accordance with EIA 481
- High surge current capability
- High current ripple
- 100% surge current test
- 100% accelerated aging in the stationary state
- RoHS compliant (6/6) to Directive 2002/95/EC
- Halogen free
- Epoxide according to UL94 V-0
- Formed epoxy conforms to ASTM E 595 emission tests
- Climate category IEC 55/125/56
- Capacity 330 µF
- Capacity_1: 330
- Unit of capacity: µF
- Capacity Tolerance 10%
- Dielectric: Ta2O5
- Equivalent Series Resistance (ESR): 0.1 ohms
- Nominal voltage DC 10 V
- Operating voltage, reduced: 6.3 V
- Packaging type
#####Tape and Reel
- Product type
Tantalum capacitor
- Type
SMD
- Capacity (elec.)
330 µF
- Nominal voltage
10 V
- Tolerance ±
10 %
- Length
7.3 mm
- Width
4.3 mm
- Height
4.1 mm
- Min. temperature
-55 °C
- Max. temperature
125 °C
- Content
1 pc(s)
- Dim
(L x W x H) 7.3 x 4.3 x 4.1 mm
- RoHS-compliant
Yes
- Type
T495X337K010ATE100
- Operating temperature (max.)
125 °C
- Operating temperature (min.)
-55 °C
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3464661 Kemet T495X337K010ATE100 Tantalum capacitor SMD 330 µF 10 V 10 % (L x W x H) 7.3 x 4.3 x 4.1 mm 1 pc(s) #####Tape and Re
User & Safety Instructions
User & Safety Instructions 3464661 Kemet T495X337K010ATE100 Tantalum capacitor SMD 330 µF 10 V 10 % (L x W x H) 7.3 x 4.3 x 4.1 mm 1 pc(s) #####Tape and Re
Description
SMD tantalum capacitors low ESR
