Kendrion Holding magnet 115 N 24 V DC 4 W HT-D25-F-24V DC 100 ED
EAN:
Part number:
Item no:
Number
Total (€ 121.84 / piece)
€ 121.84
plus VAT.
Technical specifications
- Connection: Wires
- Diameter: 25 mm
- Power-on duration: 100 % ED
- Power: 4 W
- Adhesive force 115 N
- Nominal voltage (DC) 24 V
- Type
HT-D25-F-24V DC 100 ED
- Enclosure type
Cylindrical
- Connection
Braid
- Cable length
200 mm
- Nominal voltage
24 V DC
4 W
- Holding force
115 N
- Temperature limit (max.)
130 °C
- Weight
0.0532 kg
- Time interval setting
100 %
- Width
25 mm
- (Ø)
25 mm
- Dim
(Ø) 25 mm
- RoHS-compliant
Yes
- Product type
Holding magnet
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3168417 Kendrion Holding magnet 115 N 24 V DC 4 W HT-D25-F-24V DC 100 ED
Description
Adhesive magnets Type Kuhnke HT-D. Cylindrical design; rated voltage 24 VDC, permitted relative duty cycle (ED): 100 %, connection: 200 mm long lead, insulation class: B, temperature limit: +130 °C, test voltage: 800 Veff. Technical features (type, traction, nominal power, weight): HT-D 25-F-24Vdc 100% ED, 115 N, 4.0 W, 50 g
