Kendrion Pressure switch 60.073.80.60 3 up to 8 bar 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 315.13 / piece)
€ 315.13
plus VAT.
Technical specifications
- Connector: Plug contacts
- Pressure range 3-8 bar
- Pressure medium connection M5
- Switching frequency 5 Hz
- Breaking capacity 12 VDC/6.0 A
- Type
60.073.80.60
- Product type
Pressure switch
- Min. switching pressure range
3 bar
- Max. switching pressure range
8 bar
- Switching pressure
3 up to 8 bar
- Manufacturer part #
60.073.80.60
- Connection
Jack connector
Documents & Downloads
Datasheet
Datasheet 3168376 Kendrion Pressure switch 60.073.80.60 3 up to 8 bar 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3168376 Kendrion Pressure switch 60.073.80.60 3 up to 8 bar 1 pc(s)
Description
Pneumatic pressure switch type Kuhnke 60,073. On connection plate, with adjustable switching pressure range with fixed hysteresis; operating temperature: 0 to +60 °C, housing: Plastic, diaphragm: Viton, Medium: Non-aggressive medium, switching frequency: 5.0 Hz, switching hysteresis: 0.3 bar, mechanical connections: M 5 in the base plate, electrical connections: Device socket Z 65 (flat plug connector 6.3 DIN 46247), protection type: IP 802 with plug connection, switching capacity Resistance load/inductive load: 12 VDC 6.0/6.0 A, 24 VDC 3.0/2.0 A, 220 VDC 0.25/0.2 A, 110 VDC 0.5/0.5 A, 60 VDC 1.0/0.1 A. Technical characteristics (type, switching current max. at 220 VAC, pressure switching range): 60.073.80.60, 6.0 A, 3.0 to 8.0 bar
