Kerafol KERATHERM BRAUN 70/50 TO-3 70/50 TO-3 Thermally conductive film for semiconductor enclosures 0.25 mm 1.4 W/mK
EAN:
Part number:
Item no:
Product type
Thermally conductive film for semiconductor enclosures
Thermal conductivity
1.4 W/mK
Material thickness
0.25 mm
Max. temperature
-40 °C
Type
70/50 TO-3
Datasheet (PDF)
Total (€ 0.19 / piece)
€ 1.33
plus VAT.
14-day return policy included
Highlights & Details
Keratherm heat conductivity film - Brown 70/50 for semi-conducting casing
- Thermal conductivity 1.4 W/mK
Technical specifications
- Hardness 85 shore A
- Flammability: UL 94 V-1
- Product type
Thermally conductive film for semiconductor enclosures
- Type
70/50 TO-3
- Content
1 pc(s)
- Thermal conductivity
1.4 W/mK
- Dielectric strength
16000 kV/m
- Factory colour
Brown
- Material thickness
0.25 mm
- Dim
- RoHS-compliant
Yes
- Max. temperature
-40 °C
- Min. temperature
200 °C
- Suitable for
TO 3
- Thickness
0.25 mm
- Temperature range
-40 - +200 °C
Documents & Downloads
Datasheet
Datasheet 189067 Kerafol KERATHERM BRAUN 70/50 TO-3 70/50 TO-3 Thermally conductive film for semiconductor enclosures 0.25 mm 1.4 W/mK
Security datasheet
Security datasheet 189067 Kerafol KERATHERM BRAUN 70/50 TO-3 70/50 TO-3 Thermally conductive film for semiconductor enclosures 0.25 mm 1.4 W/mK
Description
Cut to size for standard transistor casings, the 70/50 balances an economical solution with good thermal characteristics. The fibreglass reinforced film with extra-smooth surface structure features excellent heat resistant qualities and a high level of isolating capacity. Suitable for pressure sensitive applications.
