Kern ABT 120-5DNM Analytical scales Weight range 120 g Readability 0.00001 g, 0.0001 g via PSU Multicolour
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Kern ABT 120-5DNM Analytical scales Weight range 120 g Readability 0.00001 g, 0.0001 g via PSU Multicolour
- Internal Justierautomatik at temperature changes from 0.5 °C and time-controlled every 4 hours
- Dosing Cup: high stability mode and other filter settings can be selected
- Comfortable recipe picking/document with combined tare/Print function. In addition, the mix ingredients of the recipe are numbered automatically and with number/weight value expressed
- Scales identification number: 4-digit, freely programmable, expressed in the Justierprotokoll
- Automatic data output to the PC/printer after each standstill of the scales
- Single cell tip technology:
- Fully automatic production of the load cell from one piece
- Stable temperature characteristics
- Short settling time: Stable weighing values within approx. 5 sec under laboratory conditions
- High mechanical robustness
- High Corner load safety
- This text is machine translated.
Technical specifications
- Series
ABT
- Weight range
120 g
- Product type
Analytical scales
- Weight resolution
0.00001 g
- Readability
0.00001 g
0.0001 g
- Weighing plate dimensions
80 mm
- Load capacity
120 g
- Display
Digital
- Power supply (LOV)
via PSU
Manufacturer's standards (no certificate)
- Factory colour
Multicolour
- Power supply (details)
220 V - 240 V AC, 50 Hz
- Dim
(L x W x H) 340 x 215 x 335 mm
- Weight
8 kg
- Calibratable
Yes
- Calibration service
963-101
- Weighing plate
Stainless steel
- Width
215 mm
- Height
335 mm
- Length
340 mm
- Reproducibility
0.00002 g
0.0001 g
- Type
ABT 120-5DNM
- Features
Calibratable
Counting
Calibratable
- Top plate (Ø)
80 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1551626 Kern ABT 120-5DNM Analytical scales Weight range 120 g Readability 0.00001 g, 0.0001 g via PSU Multicolour
User & Safety Instructions
User & Safety Instructions 1551626 Kern ABT 120-5DNM Analytical scales Weight range 120 g Readability 0.00001 g, 0.0001 g via PSU Multicolour
Description
Hints
The selected product is a calibration approved part.If there is a need to be calibrated according to EU directives, please order the conformity assessment (calibration) via the optional accessories.Subsequent initial calibration is not possible.In the case of articles with first-time verification, the right of withdrawal is fundamentally excluded.Under the EU Directive 2014/31/EU, scales must be officially conformity-assessed ("calibrated") when used as follows:a) in the course of business, if the price of a commodity is determined by weighing.b) in the manufacture of medicinal products in pharmacies and in analyzes in the medical and pharmaceutical laboratories.c) for official purposes.d) in the manufacture of prepackages.e) in medicine.
