Kern ACJ 200-4M Analytical scales Weight range 220 g Readability 0.0001 g via PSU Multicolour
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Weight range
220 g
- Product type
Analytical scales
- Readability
0.0001 g
- Weighing plate dimensions
91 mm
- Display
Digital
- Power supply (LOV)
via PSU
Manufacturer's standards (no certificate)
- Factory colour
Multicolour
- Power supply (details)
110 V - 230 V AC
- Dim
(L x W x H) 333 x 213 x 338 mm
- Weight
7 kg
- Calibratable
Yes
- Weighing plate
Stainless steel
- Width
213 mm
- Height
338 mm
- Length
333 mm
- Reproducibility
0.0002 g
- Type
ACJ 200-4M
- Features
Calibratable
Counting
Calibratable
- Top plate (Ø)
91 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2340009 Kern ACJ 200-4M Analytical scales Weight range 220 g Readability 0.0001 g via PSU Multicolour
User & Safety Instructions
User & Safety Instructions 2340009 Kern ACJ 200-4M Analytical scales Weight range 220 g Readability 0.0001 g via PSU Multicolour
Information
Information 2340009 Kern ACJ 200-4M Analytical scales Weight range 220 g Readability 0.0001 g via PSU Multicolour
Description
ABJ-NM: Internal adjustment mechanism: In case of temperature changes ≥ 2 °C and time-controlled every 4 h, guarantees high accuracy and makes location-independant; ABS-N: Calibration program CAL: For setting the accuracy, external test weights against extra price, see test weights; ACS ABS-N: Identical with ACJ: ,: ABJ-NM: Identical in design but with standard integrated data interface RS-232 and USB; dosing aid; Convenient recipe/document: With combined tare/print function. In addition, the mixing components of the recipe are automatically numbered and printed out with number/weight value; Automatic data output to the PC/printer: After each standstill of the scales; Balance identification number:: 4-digit, freely programmable, is printed out in the calibration log; ABJ-NM has OIML certificate; work safety hood included in the delivery;
This text is machine translated.
This text is machine translated.
Scope of delivery
- - Power unit
- - Safety hood
- - Operating instructions
- - Menu overview
Hints
The selected product is a calibration approved part.If there is a need to be calibrated according to EU directives, please order the conformity assessment (calibration) via the optional accessories.Subsequent initial calibration is not possible.In the case of articles with first-time verification, the right of withdrawal is fundamentally excluded.Under the EU Directive 2014/31/EU, scales must be officially conformity-assessed ("calibrated") when used as follows:a) in the course of business, if the price of a commodity is determined by weighing.b) in the manufacture of medicinal products in pharmacies and in analyzes in the medical and pharmaceutical laboratories.c) for official purposes.d) in the manufacture of prepackages.e) in medicine.
