Kingbright KM-23ESGW SMD LED (multi-colour) SOT23 Red, Green 15 mcd 140 ° 20 mA 2.5 V Tape cut
EAN:
Part number:
Item no:
Packaging type
Tape cut
Product type
SMD LED (multi-colour)
Forward voltage U(F)
2.5 V
Forward current I(F)
20 mA
Type
SMD
Datasheet (PDF)
Number
Total (€ 0.11 / piece)
€ 0.64
-83 %
€ 0.11
plus VAT.
14-day return policy included
Kingbright KM-23ESGW SMD LED (multi-colour) SOT23 Red, Green 15 mcd 140 ° 20 mA 2.5 V Tape cut
Technical specifications
- Packaging type
Tape cut
- Product type
SMD LED (multi-colour)
- Type
KM-23ESGW
- Factory colour
Red
Green
- Forward voltage U(F)
2.5 V
- Forward current I(F)
20 mA
- Type
SMD
- Type
SOT23
- Light intensity I(V)
15 mcd
- Radiation angle
140°
- Dim
(L x W x H) 2.8 x 1.2 x 1 mm
- Length
2.8 mm
- Width
1.2 mm
- Height
1 mm
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 150311 Kingbright KM-23ESGW SMD LED (multi-colour) SOT23 Red, Green 15 mcd 140 ° 20 mA 2.5 V Tape cut
User & Safety Instructions
User & Safety Instructions 150311 Kingbright KM-23ESGW SMD LED (multi-colour) SOT23 Red, Green 15 mcd 140 ° 20 mA 2.5 V Tape cut
Description
Hints
All standard LED chips require a current-limiting resistor/constant current power source.
