KJ Electronics Electrolytic capacitor SMD 1.000 µF 25 V 20 % (Ø x H) 12 mm x 13.5 mm 1 pc(s) Tape
Part number:
Item no:
Packaging type
Tape
Product type
Electrolytic capacitor
Type
SMD
Capacity (elec.)
1.000 µF
Nominal voltage
25 V
Datasheet (PDF)
Highlights & Details
KJ Electronics SMD-Elko 1000uF 25V 12x13.5mm
Our service for you
Technical specifications
- ESD Packaging: No ESD
- Series HT
- Technology: Aluminium electrolytic capacitor
- Mounting type_1: SMD
- Delivery form_1: Taped
- Capacity 1,000 µF
- Capacity_1: 1,000
- Unit of capacity: µF
- Capacity Tolerance 20%
- Loss factor tan δ: 0.14
- Ripple current 580 mA
- Nominal voltage DC 25 V
- Lifetime_1: 2,000 h
- Packaging type
Tape
- Product type
Electrolytic capacitor
- Type
SMD
- Dim
(Ø x H) 12 mm x 13.5 mm
- Capacity (elec.)
1.000 µF
- Nominal voltage
25 V
- Tolerance ±
20 %
- Height
13.5 mm
- (Ø)
12 mm
- Content
1 pc(s)
- Material
Aluminium
- Width
12 mm
- Length
13.5 mm
- RoHS-compliant
Yes
- Max. temperature
105 °C
- Type
25HT102MLC12,5X13,5EC
- Operating temperature (max.)
105 °C
- Operating temperature (min.)
-55 °C
- Certification marks
JIS C-5141, JIS C-5102 HE
Documents & Downloads
Datasheet
Datasheet 3463076 KJ Electronics Electrolytic capacitor SMD 1.000 µF 25 V 20 % (Ø x H) 12 mm x 13.5 mm 1 pc(s) Tape
User & Safety Instructions
User & Safety Instructions 3463076 KJ Electronics Electrolytic capacitor SMD 1.000 µF 25 V 20 % (Ø x H) 12 mm x 13.5 mm 1 pc(s) Tape
Description
SMD ELECTROLYTIC CAPACITORS 10-100V 20% 105°C
