KJ Electronics Electrolytic capacitor SMD 470 µF 16 V 20 % (Ø x H) 10 mm x 10.5 mm 1 pc(s)
Part number:
Item no:
Product type
Electrolytic capacitor
Type
SMD
Capacity (elec.)
470 µF
Nominal voltage
16 V
Dim
(Ø x H) 10 mm x 10.5 mm
Datasheet (PDF)
Highlights & Details
KJ electronics SMD electrolytic capacitor 470uF 16V 10x10.5 mm
Our service for you
Technical specifications
- ESD Packaging: No ESD
- Series HT
- Technology: Aluminium electrolytic capacitor
- Mounting type_1: SMD
- Delivery form_1: Taped
- Capacity 470 µF
- Capacity_1: 470
- Unit of capacity: µF
- Capacity Tolerance 20%
- Loss factor tan δ: 0.16
- Ripple current 310 mA
- Nominal voltage DC 16 V
- Lifetime_1: 2,000 h
- Product type
Electrolytic capacitor
- Type
SMD
- Dim
(Ø x H) 10 mm x 10.5 mm
- Capacity (elec.)
470 µF
- Nominal voltage
16 V
- Tolerance ±
20 %
- Height
10.5 mm
- (Ø)
10 mm
- Content
1 pc(s)
- Material
Aluminium
- Width
10 mm
- Length
10.5 mm
- RoHS-compliant
Yes
- Max. temperature
105 °C
- Type
16HT471MLC10X10,5EC
- Operating temperature (max.)
105 °C
- Operating temperature (min.)
-55 °C
- Certification marks
JIS C-5141, JIS C-5102 HE
Documents & Downloads
Datasheet
Datasheet 3463073 KJ Electronics Electrolytic capacitor SMD 470 µF 16 V 20 % (Ø x H) 10 mm x 10.5 mm 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3463073 KJ Electronics Electrolytic capacitor SMD 470 µF 16 V 20 % (Ø x H) 10 mm x 10.5 mm 1 pc(s)
Description
SMD ELECTROLYTIC CAPACITORS 10-100V 20% 105°C
