KJ Electronics Electrolytic capacitor SMD 470 µF 35 V 20 % 1 pc(s) Tape
Part number:
Item no:
Packaging type
Tape
Product type
Electrolytic capacitor
Type
SMD
Capacity (elec.)
470 µF
Nominal voltage
35 V
Datasheet (PDF)
Highlights & Details
KJ electronics SMD electrolytic capacitor 470uF 35V 12.5x13.5mm
Our service for you
Technical specifications
- ESD Packaging: No ESD
- Series: LZ
- Technology: Aluminium electrolytic capacitor
- Mounting type_1: SMD
- Delivery form_1: Taped
- Properties_1: • Low impedance
- Capacity 470 µF
- Capacity_1: 470
- Unit of capacity: µF
- Capacity Tolerance 20%
- Loss factor tan δ: 0.12
- Ripple current 820 mA
- Nominal voltage DC 35 V
- Lifetime_1: 2,000 h
- Packaging type
Tape
- Product type
Electrolytic capacitor
- Type
SMD
- Capacity (elec.)
470 µF
- Nominal voltage
35 V
- Tolerance ±
20 %
- Height
13.5 mm
- Content
1 pc(s)
- Material
Aluminium
- RoHS-compliant
Yes
- Max. temperature
105 °C
- Type
35LZ471MLC12.5X13.5EC
- Operating temperature (max.)
105 °C
- Operating temperature (min.)
-55 °C
- Certification marks
JIS C-5141, JIS C-5102 HE
Documents & Downloads
Datasheet
Datasheet 3463083 KJ Electronics Electrolytic capacitor SMD 470 µF 35 V 20 % 1 pc(s) Tape
User & Safety Instructions
User & Safety Instructions 3463083 KJ Electronics Electrolytic capacitor SMD 470 µF 35 V 20 % 1 pc(s) Tape
Description
SMD electrolytic capacitors 16-50V 20% 105°C low ESR
