Klauke 50610809 Punch form
EAN:
Part number:
Item no:
Technical specifications
- Design: Complete (with draw bolt)
- Hole diameter 12.7 mm
- Splitting hole: No.
- Hole width 15.9 mm
- Hole height 15.1 mm
- Hydraulic actuation type: Yes
- Mechanical actuation: Yes
- Product type
Punch form
- Material suitability
Steel
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3429831 Klauke 50610809 Punch form
Description
Suitable for steel sheet (ST37), plastic and aluminum up to 2.0 mm thickness. Complete system consisting of stamp, die plate, traction screw, lock nut and ball bearing nut. Manual and hydraulic actuation. Pre-drilling with 12.7 mm diameter pre-drill 50344102.
